padosoft / product-image-discovery
Laravel package for conservative product image discovery, verification, scoring, download, and manual review workflows.
Package info
github.com/padosoft/product_image_discovery
pkg:composer/padosoft/product-image-discovery
Requires
- php: ^8.3
- illuminate/bus: ^13.0
- illuminate/cache: ^13.0
- illuminate/console: ^13.0
- illuminate/contracts: ^13.0
- illuminate/database: ^13.0
- illuminate/filesystem: ^13.0
- illuminate/http: ^13.0
- illuminate/log: ^13.0
- illuminate/queue: ^13.0
- illuminate/routing: ^13.0
- illuminate/support: ^13.0
- illuminate/validation: ^13.0
- laravel/ai: ^0.6.5
- laravel/sanctum: ^4.2
- padosoft/laravel-ai-regolo: ^0.2.3
- padosoft/laravel-ai-search-providers: ^1.0
Requires (Dev)
- mockery/mockery: ^1.6
- orchestra/testbench: ^11.0
- phpunit/phpunit: ^12.0
- dev-main
- v1.0.0
- v0.3.0
- v0.2.0
- v0.1.3
- v0.1.2
- v0.1.1
- v0.1.0
- dev-docs/refresh-supported-providers
- dev-chore/v1-release
- dev-refactor/depend-on-ai-search-providers
- dev-refactor/abstract-search-providers
- dev-feat/search-provider-duckduckgo
- dev-feat/search-provider-websearchapi
- dev-feat/search-provider-firecrawl
- dev-feat/search-provider-exa
- dev-feat/search-provider-tavily
This package is auto-updated.
Last update: 2026-05-23 20:10:07 UTC
README
Table of Contents
- Responsible Use Disclaimer
- Why This Package
- Quick Start (5 minutes, junior-friendly)
- Supported Search Providers
- What It Does
- Architecture
- Web Admin UI
- Request Flow
- Installation
- Live Smoke Test From A Fresh Laravel App
- Debug Flow Command
- Quickstart
- EAN / Barcode Matching
- Real Product Payload Examples
- Configuration
- Trusted Sources
- Optional Playwright Sidecar
- AI And Vision
- Testing
- Database Tables
- Safety Notes
- Admin UI Guidance
- Roadmap
- Contributing
- License & credits
Find the right product image, not just any image.
padosoft/product-image-discovery is a Laravel package for discovering, verifying, scoring and preparing product images from supplier data, search providers and trusted sources. It is built for catalog teams, ERPs, PIMs and marketplaces where the expensive mistake is not "we found no image"; the expensive mistake is publishing the wrong image for a product-color variant.
The package gives you a conservative pipeline, an API for ingestion and review, database-backed configuration, queue-ready jobs, audit events and an optional Playwright sidecar for pages that need browser rendering.
Responsible Use Disclaimer
Use this package only for lawful, authorized product image discovery workflows. Do not use it to abuse third-party services, bypass access controls, overload websites, violate robots.txt or source terms, or collect images from sources where you do not have explicit permission or another valid legal basis. Configure trusted sources, rate limits and manual review policies conservatively, and use it only on websites, suppliers, brand sources or search providers that you are allowed to access for this purpose.
Why This Package
- Conservative by design: it optimizes for low false positives.
- Product-color aware: the main identity is
client_id + erp_model_color_id. - Explainable decisions: candidates carry source, score, quality and audit context.
- Laravel native: service provider, config, migrations, Eloquent models, form requests, resources, Sanctum-friendly middleware and queue jobs.
- Provider-ready: search providers are configured in the database and resolved through a manager.
- Browser optional: Playwright runs in a separate Node sidecar and is not required for basic usage.
- AI-assisted, not AI-dependent: optional LLM/vision verification can enrich decisions without making the core fragile.
- Testable offline: the default test suite uses SQLite, fake providers and deterministic sidecar tests.
Quick Start (5 minutes, junior-friendly)
Goal: from a fresh Laravel 13 app to a passing end-to-end discovery request, without paid keys, copy-pasting nine blocks in order. The pipeline runs synchronously and returns a stored candidate from a bundled fake provider, so you can see the full flow before plugging in any external API.
Prerequisites: PHP 8.3+, Composer, a clean Laravel 13 app, ~5 minutes. No queue worker, no Redis, no Node, no API keys.
1. Require the package
composer require padosoft/product-image-discovery
2. Publish config
php artisan vendor:publish --tag=product-image-discovery-config
3. Publish migrations
php artisan vendor:publish --tag=product-image-discovery-migrations
4. Create the SQLite database file
touch database/database.sqlite
On Windows PowerShell:
New-Item -ItemType File database/database.sqlite -Force
5. Migrate
php artisan migrate
6. Seed default settings + provider templates
php artisan db:seed --class="Padosoft\ProductImageDiscovery\Database\Seeders\ProductImageDiscoveryDefaultsSeeder"
7. Minimal .env overrides (append four lines)
DB_CONNECTION=sqlite DB_DATABASE=database/database.sqlite QUEUE_CONNECTION=sync PRODUCT_IMAGE_DISCOVERY_ROUTE_PREFIX=api/product-image-discovery
8. Activate the bundled fake provider + issue a token via tinker
php artisan tinker
Inside Tinker, paste this single block:
Copy the printed token. Exit tinker.
If
App\Models\Userdoes not useLaravel\Sanctum\HasApiTokens, add the trait first — see step 4 in Live Smoke Test From A Fresh Laravel App.
9. Hit the API (replace YOUR_TOKEN)
php artisan serve
In another terminal:
curl -X POST "http://127.0.0.1:8000/api/product-image-discovery/requests" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json" \ -H "Content-Type: application/json" \ -d '{ "client_id": 1, "erp_model_id": "DEMO-1", "erp_model_color_id": "DEMO-1-BLACK", "brand": "Demo", "model_code": "DEMO-1", "color_name": "Black" }'
You should receive {"ok":true, "request_id":1, "status":"queued"}.
✅ Done — you just ran the full ingest → search → extract → verify → download → quality pipeline locally with a deterministic fake provider. Next steps:
- Enable a real provider (Brave, Tavily, Exa.ai, Firecrawl, WebSearchAPI.ai, DuckDuckGo, SearchAPI.io, You.com): see Supported Search Providers below.
- Run the live debug flow with a real product payload: see Debug Flow Command.
- Full host-app walkthrough with Sanctum scopes and Brave: see Live Smoke Test From A Fresh Laravel App.
Supported Search Providers
Since v1.0.0, the search layer is consumed via the standalone composer package
padosoft/laravel-ai-search-providers. This repo declares it as a hard dependency incomposer.json; the package ships every driver listed below, theSearchProviderInterfacecontract, theSearchProviderManagerorchestrator, the DTOs, the Eloquent model and the create-table migration.product-image-discoveryonly exposes a backwards-compatibleProductImageSearchProviderEloquent subclass that hard-codes the legacyproduct_image_search_providerstable, so existing host apps and the sisterpadosoft/product_image_discovery_adminpackage keep working unchanged. For full driver documentation, theHttp::faketest pattern, custom-driver extension and the package Quick Start, jump to the package README at https://github.com/padosoft/laravel-ai-search-providers#readme.
The package currently bundles 9 search providers — 1 deterministic for tests + 8 live drivers covering global, EU-friendly, free-tier and scrape-friendly options. All providers are stored in the same product_image_search_providers table and resolved through a single SearchProviderManager, so swapping one for another is a row update.
| Provider | Driver | Image search | Site filter | Free tier | Docs |
|---|---|---|---|---|---|
| Fake (deterministic) | fake |
✅ | ✅ | — | n/a — bundled for tests |
| Brave Search | brave |
✅ | ✅ | 2000 / month | https://api-dashboard.search.brave.com/app/documentation |
| Tavily | tavily |
✅ | ✅ (include_domains) |
1000 credits / month | https://docs.tavily.com |
| Exa.ai | exa |
✅ (extras.imageLinks) |
✅ (includeDomains) |
Free trial credits | https://docs.exa.ai |
| Firecrawl | firecrawl |
✅ (sources:["images"]) |
✅ (via site: operator) |
500 credits / month | https://docs.firecrawl.dev/api-reference/v2-endpoint/search |
| WebSearchAPI.ai | websearchapi |
❌ (web-only) | ✅ (includeDomains) |
Free trial credits | https://websearchapi.ai/docs/search-api |
| DuckDuckGo (HTML lite) | duckduckgo |
❌ | ✅ (via site: operator) |
No key required | https://duckduckgo.com/html/ |
| SearchAPI.io | searchapi |
✅ (engine=google_images) |
✅ (via site: operator) |
Free trial credits | https://www.searchapi.io/docs/google-images |
| You.com | youcom |
❌ (web-only) | ✅ (include_domains) |
Free trial credits | https://you.com/docs/api-reference/search/v1-search |
Templates for
serpapiandgoogle_custom_searchwere originally seeded but Google's Custom Search JSON API was closed to new customers in 2026 and new Programmable Search Engines can no longer index the full web — see the Roadmap for the Vertex AI Search / Agent Search adapter slated as a separate sub-package.
⚠️ Provider configs are redacted in audit logs. Always store secrets in
.envand let the seeders/tinker scripts populateapi_key_encrypted, never expose API keys through user-facing endpoints.
Brave Search
BRAVE_SEARCH_API_KEY=your-key
Activate the seeded provider:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'brave')->firstOrFail(); $p->api_key_encrypted = env('BRAVE_SEARCH_API_KEY'); $p->is_active = true; $p->save();
Tavily
JSON search API with first-class image support (images[]) and include_domains site filtering.
TAVILY_API_KEY=your-key TAVILY_URL=https://api.tavily.com
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'tavily')->firstOrFail(); $p->api_key_encrypted = env('TAVILY_API_KEY'); $p->is_active = true; $p->save();
Exa.ai
POST /search with contents.extras.imageLinks per result, flattened into one candidate per image URL. Site filter via includeDomains. Auth via x-api-key header.
EXA_API_KEY=your-key EXA_URL=https://api.exa.ai
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'exa')->firstOrFail(); $p->api_key_encrypted = env('EXA_API_KEY'); $p->is_active = true; $p->save();
The image_links_per_result config key (default 5) caps how many imageLinks Exa returns per result and how many candidates the provider emits per Exa result.
Firecrawl
POST /v2/search with sources:[{type:"images"}] (or [{type:"web"}] for searchWeb()). Bearer auth. Site filter propagated as includeDomains array. Returns data.images[] with imageUrl, imageWidth, imageHeight, and the source page url.
FIRECRAWL_API_KEY=your-key FIRECRAWL_URL=https://api.firecrawl.dev
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'firecrawl')->firstOrFail(); $p->api_key_encrypted = env('FIRECRAWL_API_KEY'); $p->is_active = true; $p->save();
WebSearchAPI.ai
POST /ai-search with Bearer auth. Google-backed organic web results with optional AI content extraction. Site filter via includeDomains. Web-only: WebSearchAPI does not expose a dedicated image search endpoint, so supportsImageSearch() returns false and SearchProviderManager skips this driver for image queries (the extraction pipeline can still harvest images from the returned pages).
WEBSEARCHAPI_API_KEY=your-key WEBSEARCHAPI_URL=https://api.websearchapi.ai
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'websearchapi')->firstOrFail(); $p->api_key_encrypted = env('WEBSEARCHAPI_API_KEY'); $p->is_active = true; $p->save();
DuckDuckGo (HTML lite)
Free, no-API-key fallback for web search. Posts to https://html.duckduckgo.com/html/ and parses the response with \DOMDocument + \DOMXPath. Result .result__a links use the //duckduckgo.com/l/?uddg=<encoded> redirect form — the provider decodes them transparently and returns the real destination URL. No image search: supportsImageSearch() returns false, so SearchProviderManager skips it for image queries automatically.
# Optional override (defaults to https://html.duckduckgo.com): DUCKDUCKGO_URL=https://html.duckduckgo.com
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'duckduckgo')->firstOrFail(); $p->base_url = 'https://html.duckduckgo.com'; $p->is_active = true; $p->save();
Use it sparingly and respect DuckDuckGo's terms — it is best as a low-volume fallback, not a primary driver. DuckDuckGo applies anti-bot rate limits to shared/datacenter IPs; the live E2E test self-skips in CI and on 403/429/503 responses.
SearchAPI.io
Single GET /api/v1/search endpoint that switches between engine=google_images (image search → images[] with original.link, original.{width,height}, thumbnail, source.{link,name}) and engine=google (web search → organic_results[]). Bearer auth. Site filter appended as site:<host> operator in the query. Added by padosoft/laravel-ai-search-providers v1.2.0.
SEARCHAPI_API_KEY=your-key SEARCHAPI_URL=https://www.searchapi.io
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::query()->create([ 'code' => 'searchapi', 'name' => 'SearchAPI.io', 'driver' => 'searchapi', 'base_url' => 'https://www.searchapi.io', 'api_key_encrypted' => env('SEARCHAPI_API_KEY'), 'config' => ['country' => 'us', 'language' => 'en'], 'priority' => 90, 'timeout_seconds' => 30, 'is_active' => true, ]);
You.com
GET /v1/search against https://ydc-index.io with X-API-Key header. Parses results.web[] (and optionally results.news[]) with title, url, description, snippets[], thumbnail_url, page_age, favicon_url. Site filter propagated as include_domains (comma-separated). Web-only as of 2026-05: You.com does not expose a dedicated image-search endpoint, so supportsImageSearch() returns false and SearchProviderManager skips this driver for image queries automatically — thumbnail_url is still surfaced per result, and the extraction pipeline can still harvest images from the returned pages. Added by padosoft/laravel-ai-search-providers v1.2.0.
YOUCOM_API_KEY=your-key YOUCOM_URL=https://ydc-index.io
Activate:
$p = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::query()->create([ 'code' => 'youcom', 'name' => 'You.com', 'driver' => 'youcom', 'base_url' => 'https://ydc-index.io', 'api_key_encrypted' => env('YOUCOM_API_KEY'), 'config' => ['country' => 'US', 'safesearch' => 'moderate'], 'priority' => 100, 'timeout_seconds' => 30, 'is_active' => true, ]);
Fake provider
Deterministic, no network. Use it for local smoke tests, CI and unit tests. See the Quick Start above for an example configuration that feeds an inline base64 image directly into the download/quality steps.
What It Does
- Ingests product identity payloads from ERP, PIM or catalog systems.
- Generates targeted search queries from brand, model, SKU, supplier SKU, EAN and color.
- Searches configurable providers.
- Extracts image candidates from search results, structured data, Open Graph tags and gallery-like markup.
- Deduplicates candidates by stable fingerprints.
- Scores candidates against product identity, source trust and image quality.
- Downloads and stores accepted candidate assets.
- Routes uncertain matches to manual review.
- Records audit events for decisions and retries.
Architecture
The package is split into small layers so you can replace the parts that touch infrastructure:
- API layer:
/api/product-image-discovery/...endpoints for request ingestion, search, candidate review and configuration. - Persistence layer: migrations and Eloquent models for requests, candidates, source pages, settings, trusted sources, providers and audit events.
- Pipeline layer: queue jobs for ingest, search, extraction, verification, download and quality assessment.
- Search layer: provider definitions, database repository, provider manager and provider factories.
- Decision layer: deterministic scoring, anti-false-positive checks and quality thresholds.
- Sidecar layer: optional Node service for rendering JavaScript-heavy product pages with Playwright.
Web Admin UI
Need a ready-made back office for this package? The professional Laravel admin is already available as a sister repository:
padosoft/product_image_discovery_admin
It provides an operational dashboard, request review queues, candidate comparison, protected image previews, approve/reject/retry actions, provider and trusted-source configuration, debug-flow execution, health checks, report inspection, API workbench tooling, CSV export, saved demo filters and a GitHub Actions release gate.
Request Flow
flowchart TD
A[ERP / PIM / Catalog sends product payload] --> B[POST /api/product-image-discovery/requests]
B --> C[Validate payload with StoreProductImageDiscoveryRequest]
C --> D[Upsert discovery request by client_id + erp_model_color_id]
D --> E[Store full payload in raw_payload]
E --> F[Dispatch configured ingest job]
F --> G[IngestProductImageDiscoveryJob]
G --> H{Payload or request id?}
H -->|Raw payload| I[Normalize ProductIdentityData]
H -->|Request id| J[Resume persisted request]
I --> K[Mark request queued]
J --> K
K --> L[Dispatch SearchProductImageJob]
L --> M[Generate deterministic search queries]
M --> N[SearchProviderManager executes active providers]
N --> O{Results found?}
O -->|No| P[Mark no_candidates_found]
O -->|Yes| Q[Store search context and mark candidates_found]
Q --> R[Dispatch ExtractCandidateSourcesJob]
R --> S[Create source pages and candidate images]
S --> T[Deduplicate by request_id + fingerprint]
T --> U[Dispatch VerifyCandidateImageJob]
U --> V[Score source, text, structured data and hard rejection reasons]
V --> W[Dispatch DownloadCandidateImageJob]
W --> X[Download or persist inline image data]
X --> Y[Dispatch AssessImageQualityJob]
Y --> Z[Measure dimensions, size and quality signals]
Z --> AA{Decision threshold}
AA -->|Strong match| AB[Candidate quality_passed / ready for selection]
AA -->|Uncertain| AC[Manual review]
AA -->|Weak or unsafe| AD[Rejected with reason]
AB --> AE[Audit event + API review endpoints]
AC --> AE
AD --> AE
Loading
Installation
Requirements:
- PHP 8.3 or newer.
- Laravel 13.
- Composer.
- A database supported by Laravel. SQLite is enough for a local smoke test.
- A queue driver.
syncis easiest for a first test; Redis/Horizon is better for production.
1. Require the package
composer require padosoft/product-image-discovery
If you are testing directly from GitHub before Packagist is updated, add the repository first:
composer config repositories.product-image-discovery vcs https://github.com/padosoft/product_image_discovery.git composer require padosoft/product-image-discovery:0.1.0
2. Review the env examples
The repository ships two examples:
.env.example: useful for a fresh Laravel demo app or for package development.sidecar/.env.example: useful when running the optional Node/Playwright sidecar.
For a local smoke test, the important host-app values are:
DB_CONNECTION=sqlite DB_DATABASE=database/database.sqlite QUEUE_CONNECTION=sync FILESYSTEM_DISK=local PRODUCT_IMAGE_DISCOVERY_ROUTE_PREFIX=api/product-image-discovery PRODUCT_IMAGE_DISCOVERY_STORAGE_DISK=local PRODUCT_IMAGE_DISCOVERY_DEBUG_STOP_ON_FIRST_GOOD=true PRODUCT_IMAGE_DISCOVERY_DEBUG_GOOD_SCORE_THRESHOLD=65
3. Publish the config
php artisan vendor:publish --tag=product-image-discovery-config
This creates:
config/product-image-discovery.php
4. Publish the migrations
php artisan vendor:publish --tag=product-image-discovery-migrations
5. Run migrations
php artisan migrate
6. Seed default settings and provider templates
php artisan db:seed --class="Padosoft\ProductImageDiscovery\Database\Seeders\ProductImageDiscoveryDefaultsSeeder"
The seeder creates default matching thresholds, quality settings and disabled provider templates such as Brave, SerpAPI and Google Custom Search.
7. Configure Sanctum abilities
The API middleware expects token abilities like:
product-image-discovery:read
product-image-discovery:write
product-image-discovery:review
product-image-discovery:settings
product-image-discovery:admin
For a back-office integration, give operators read and review; give system ingestion tokens write; reserve settings and admin for trusted maintainers.
8. Configure queues
By default, jobs use dedicated queue names:
'queues' => [ 'ingest' => 'image-discovery-ingest', 'search' => 'image-discovery-search', 'extract' => 'image-discovery-extract', 'verify' => 'image-discovery-verify', 'download' => 'image-discovery-download', 'quality' => 'image-discovery-quality', ],
Run your Laravel queue workers as usual:
php artisan queue:work
If you use Horizon, map these queues in config/horizon.php.
Live Smoke Test From A Fresh Laravel App
This path is intentionally explicit so a junior developer can prove the package works in a real Laravel application without setting up Redis, MySQL or a paid search API.
1. Create a clean Laravel app
composer create-project laravel/laravel product-image-discovery-demo "^13.0" cd product-image-discovery-demo
2. Install the package from GitHub tag v0.1.0
composer config repositories.product-image-discovery vcs https://github.com/padosoft/product_image_discovery.git composer require padosoft/product-image-discovery:0.1.0
3. Configure .env
Create the SQLite database file:
touch database/database.sqlite
On Windows PowerShell:
New-Item -ItemType File database/database.sqlite -Force
Set these values in the Laravel app .env:
APP_URL=http://127.0.0.1:8000 DB_CONNECTION=sqlite DB_DATABASE=database/database.sqlite QUEUE_CONNECTION=sync FILESYSTEM_DISK=local PRODUCT_IMAGE_DISCOVERY_ROUTE_PREFIX=api/product-image-discovery PRODUCT_IMAGE_DISCOVERY_STORAGE_DISK=local PRODUCT_IMAGE_DISCOVERY_DEBUG_STOP_ON_FIRST_GOOD=true PRODUCT_IMAGE_DISCOVERY_DEBUG_GOOD_SCORE_THRESHOLD=65
Then generate the app key:
php artisan key:generate
4. Install Sanctum tables and enable API tokens
php artisan vendor:publish --provider="Laravel\Sanctum\SanctumServiceProvider"
In app/Models/User.php, make sure the model uses Sanctum tokens:
use Laravel\Sanctum\HasApiTokens; class User extends Authenticatable { use HasApiTokens; }
Keep any existing traits such as HasFactory and Notifiable; just add HasApiTokens.
5. Publish package files and migrate
php artisan vendor:publish --tag=product-image-discovery-config
php artisan vendor:publish --tag=product-image-discovery-migrations
php artisan migrate
php artisan db:seed --class="Padosoft\ProductImageDiscovery\Database\Seeders\ProductImageDiscoveryDefaultsSeeder"
6. Create a test API token
php artisan tinker
Inside Tinker:
$user = \App\Models\User::factory()->create(['email' => 'pid-demo@example.test']); $token = $user->createToken('pid-demo', [ 'product-image-discovery:read', 'product-image-discovery:write', 'product-image-discovery:review', 'product-image-discovery:settings', 'product-image-discovery:admin', ])->plainTextToken; $token;
Copy the printed token for the Authorization: Bearer ... header.
7. Add a deterministic fake provider
This provider lets you test the whole API and queue path without a paid search API:
php artisan tinker
Inside Tinker:
8. Start the app
php artisan serve
9. Send a real API request
Replace YOUR_TOKEN with the Sanctum token from step 6:
curl -X POST "http://127.0.0.1:8000/api/product-image-discovery/requests" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json" \ -H "Content-Type: application/json" \ -d '{ "client_id": 1, "erp_model_id": "NIKE-AF1-07", "erp_model_color_id": "NIKE-AF1-07-CW2288-111", "brand": "Nike", "supplier": "Nike", "supplier_sku": "CW2288-111", "model_code": "Air Force 1 07", "color_code": "CW2288-111", "color_name": "White", "category": "Sneakers", "material": "Leather" }'
The same payload is available as a ready-to-edit JSON file:
curl -X POST "http://127.0.0.1:8000/api/product-image-discovery/requests" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json" \ -H "Content-Type: application/json" \ --data @examples/requests/nike-air-force-1-live.json
You should receive a JSON response with ok: true and a request_id. Because QUEUE_CONNECTION=sync, the pipeline runs during the request cycle.
Check the stored request:
curl "http://127.0.0.1:8000/api/product-image-discovery/requests/1" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json"
10. Optional: activate Brave for a real external search
Add your key to .env:
BRAVE_SEARCH_API_KEY=your-real-key
Then activate the seeded Brave provider:
php artisan tinker
Inside Tinker:
$provider = \Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'brave')->firstOrFail(); $provider->api_key_encrypted = env('BRAVE_SEARCH_API_KEY'); $provider->is_active = true; $provider->save();
Disable the fake provider when you want only live search results:
\Padosoft\ProductImageDiscovery\Models\ProductImageSearchProvider::where('code', 'fake-smoke')->update(['is_active' => false]);
Debug Flow Command
The package includes a console command for full live debugging from a request JSON file. It runs the same pipeline jobs as the queue flow and streams a step-by-step console trace: ingest, generated queries, sites/images found, candidate verification order, every candidate examined, score components, deterministic evidence, optional AI output, download path, hash, quality analysis, errors and final decision.
Before verification, the command ranks candidates with deterministic scoring, so constrained runs start from the strongest product identity match and avoid spending live AI calls on obvious wrong-color or wrong-model candidates first. Use --report=... to keep the complete JSON report on disk; use --json when you need machine-readable output instead of the live console trace.
Where to run it:
- Inside a host Laravel app that installed the package, use
php artisan .... - Inside this package repository, there is no
artisanfile. Use Orchestra Testbench throughvendor/bin/testbench.
What you see on screen:
- ASCII art header, so debug runs are easy to spot in terminal history.
- Request ingest: JSON file path,
client_id,erp_model_color_id, brand, model and color identity. - Search step: provider used, generated queries, executed query attempts, query weights, result count and provider attempts.
- Found sites and images: source domain, page URL, image URL, title and image dimensions for each provider result.
- Extraction step: candidate ids and source pages retained from the search results.
- Candidate plan: deterministic debug rank and the exact order in which candidates will be examined.
- Per-candidate verification: candidate URL, source page, source policy, score components, final score, matches, mismatches, strong matches and rejection reason.
- AI verification output when enabled: provider, model, status, match flags, confidence, brand/model/color/type/quality booleans, AI rejection reason, notes and errors.
- Download step: selected candidate id, remote image URL, local storage path, MIME type, bytes and SHA-256 hash.
- Quality analysis: pass/fail, quality score, dimensions, MIME type and quality issues.
- Final decision: request status, selected/best candidate id, final score, verified match count and report path.
- Audit events: persisted event type, level, candidate id and JSON context for later inspection.
php artisan product-image-discovery:debug-flow examples/requests/herno-cappa-nylon-ultralight-cammello.json
That php artisan form only works from a Laravel app root. If you run it from the package root and see Could not open input file: artisan, use the Testbench commands in the Herno example below.
Useful options:
php artisan product-image-discovery:debug-flow examples/requests/herno-cappa-nylon-ultralight-cammello.json \ --fresh \ --max-candidates=10 \ --report=storage/app/product-image-discovery/debug/herno-flow.json
--fresh: deletes the existing request for the sameclient_id + erp_model_color_idbefore running.--max-candidates=10: limits how many discovered candidates are verified in this debug run.--report=...: writes the complete JSON report to disk while still printing the formatted console output.--json: prints only the JSON report and disables the live console trace.--no-download: skips download and quality assessment.--download-all: downloads and quality-assesses every verified candidate; by default only the best verified candidate is downloaded.--clean-storage: deletes theproduct-image-discovery/{request_id}storage directory before downloading, useful when repeating debug runs.--stop-on-first-good: stops verifying more candidates after a good verified candidate is found.--exhaustive: verifies every candidate up to--max-candidates, ignoring the early-stop setting.--good-score=65: overrides the score threshold used by early stop.--migrate: runs migrations first, useful in local demo/Testbench environments.--no-env-brave: disables automatic creation of abrave-live-debugprovider fromBRAVE_SEARCH_API_KEY.--fail-on-no-match: exits with a failure code when no candidate reachesverified_match.
Early stop is controlled by:
PRODUCT_IMAGE_DISCOVERY_DEBUG_STOP_ON_FIRST_GOOD=true PRODUCT_IMAGE_DISCOVERY_DEBUG_GOOD_SCORE_THRESHOLD=65
With early stop enabled, the command stops candidate verification when a verified candidate is good enough because it comes from an auto-publish/trusted source, the source domain contains the brand, or its final score reaches the configured threshold. Use --exhaustive when you intentionally want to inspect all candidates up to --max-candidates.
--fresh also cleans the storage directory for the matching old request ids and the new debug request id. This matters especially when running from the package with Testbench: the database is often SQLite in-memory, so request ids can restart from 1 while physical files under vendor/orchestra/testbench-core/laravel/storage/... remain from older debug or live test runs.
To inspect and download every verified candidate in a broad run, combine:
php artisan product-image-discovery:debug-flow examples/requests/herno-cappa-nylon-ultralight-cammello.json \ --exhaustive \ --download-all \ --max-candidates=10
Herno Live Debug Example
The repository includes a real fashion request example without any source page or image URL:
examples/requests/herno-cappa-nylon-ultralight-cammello.json
It describes:
- Brand:
Herno - Model/code:
PI002223D - Product:
Cappa In Nylon Ultralight Cammello - Color:
Cammello - Category:
Donna > Maglie e camicie > Felpe e maglie - Material:
100% Nylon
Run it in a host Laravel app:
php artisan product-image-discovery:debug-flow examples/requests/herno-cappa-nylon-ultralight-cammello.json \ --fresh \ --max-candidates=10 \ --report=storage/app/product-image-discovery/debug/herno-flow.json
Run it from this package with Testbench on Windows PowerShell:
$env:APP_KEY = 'base64:' + [Convert]::ToBase64String([Text.Encoding]::ASCII.GetBytes(('a' * 32))) $env:DB_CONNECTION='sqlite' $env:DB_DATABASE=':memory:' $request = (Resolve-Path .\examples\requests\herno-cappa-nylon-ultralight-cammello.json).Path $report = Join-Path (Get-Location) 'storage\debug\herno-flow.json' & 'C:\Users\lopad\.config\herd\bin\php84\php.exe' vendor\bin\testbench product-image-discovery:debug-flow $request --migrate --fresh --max-candidates=10 --report=$report
Run it from this package with Testbench on macOS/Linux shell:
export APP_KEY="$(php -r 'echo "base64:".base64_encode(str_repeat("a", 32));')" export DB_CONNECTION=sqlite export DB_DATABASE=':memory:' request="$(pwd)/examples/requests/herno-cappa-nylon-ultralight-cammello.json" report="$(pwd)/storage/debug/herno-flow.json" php vendor/bin/testbench product-image-discovery:debug-flow "$request" --migrate --fresh --max-candidates=10 --report="$report"
With BRAVE_SEARCH_API_KEY configured, the command auto-creates a brave-live-debug provider and shows the live Brave image results. Search queries prefer product-code + color combinations before bare product-code searches, so fashion variants such as PI002223D CAMMELLO are tried before broader PI002223D searches. With AI enabled and PRODUCT_IMAGE_DISCOVERY_AI_ATTACH_REMOTE_IMAGE=true, it also sends each verified candidate image URL to the configured vision model and prints the full AI verification result.
The AI verifier is instructed to inspect the actual attached image first. Numeric vendor color ids in URLs or DOM metadata are not treated as color names: if the image visibly looks camel/tan/beige/cammello, the model can mark the requested color as equivalent; if the image visibly shows a different product or color, for example white shoes, it should mark match=false, variant_safe=false, color_match=false and product_type_match=false.
In the local Herno run, the trace found the official us.herno.com image, downloaded it under product-image-discovery/{request_id}/{candidate_id}.jpg, quality-checked it, printed the SHA-256 hash, and kept the request in manual_review because the source was not configured as auto-publishable. External results and AI wording can change, so treat the report as the source of truth for each run.
Downloaded image paths:
- The command prints the logical path stored on the configured Laravel disk, for example
product-image-discovery/1/4.jpg. - In a host Laravel app with
PRODUCT_IMAGE_DISCOVERY_STORAGE_DISK=local, that file is physically under the app storage directory, for examplestorage/app/private/product-image-discovery/1/4.jpg. - When running from this package with Testbench, the Laravel app is Testbench's skeleton app, so the physical file is under
vendor/orchestra/testbench-core/laravel/storage/app/private/product-image-discovery/1/4.jpg. - If you change
PRODUCT_IMAGE_DISCOVERY_STORAGE_DISK, inspect the root configured for that disk in the host app'sconfig/filesystems.php.
Console screenshots:
Quickstart
Send a product-color payload:
curl -X POST "https://your-app.test/api/product-image-discovery/requests" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json" \ -H "Content-Type: application/json" \ -d '{ "client_id": 10, "erp_model_color_id": "SHOE-123-BLACK", "erp_model_id": "SHOE-123", "brand": "Example Brand", "supplier": "Main Supplier", "sku": "SHOE-123-BLK-42", "supplier_sku": "SUP-9988", "model_code": "SHOE-123", "color_code": "BLK", "color_name": "Black", "ean": "8050000000000", "season": "FW26", "category": "Sneakers", "material": "Leather" }'
Example response:
{
"ok": true,
"request_id": 1,
"erp_model_color_id": "SHOE-123-BLACK",
"status": "queued"
}
Search requests:
curl "https://your-app.test/api/product-image-discovery/requests/search?status=manual_review" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json"
Approve a candidate:
curl -X POST "https://your-app.test/api/product-image-discovery/requests/1/candidates/5/approve" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json"
Reject a candidate:
curl -X POST "https://your-app.test/api/product-image-discovery/requests/1/candidates/5/reject" \ -H "Authorization: Bearer YOUR_TOKEN" \ -H "Accept: application/json" \ -H "Content-Type: application/json" \ -d '{"reason": "wrong_color", "notes": "The image shows the white variant."}'
EAN / Barcode Matching
ean is optional, but when your ERP/PIM/supplier has the real product barcode it is one of the strongest identity signals in the package.
Accepted payload aliases:
ean
barcode
bar_code
gtin
gtin13
gtin14
The API normalizes these aliases into the stored ean field. When ean is present:
- search query generation tries the brand + EAN query first with the highest weight;
- source patterns can use
{ean}; - textual matches against the discovered page/image metadata count as a strong product identity match;
- structured data matches against
gtin,gtin8,gtin12,gtin13,gtin14oreancount as a strong match; - a structured GTIN/EAN mismatch is treated as a wrong-product risk;
- even an exact EAN match does not override crucial contradictions such as wrong visible color, wrong product type, wrong brand, permission limits or low-quality image evidence.
Do not invent barcodes for smoke tests. Leave ean/barcode empty unless the value comes from the real catalog, supplier or product feed.
Real Product Payload Examples
These examples are realistic ERP/PIM payloads for products that also exist on public fashion sites. The request intentionally does not include an image URL or product page URL: discovering that page/image is the job of the package. Ecommerce pages can change, go out of stock or block automated access, so treat these as smoke-test payloads rather than permanent fixtures. Do not invent EANs: leave ean empty unless your ERP/PIM has the real barcode.
Ready-to-edit request files are available in:
examples/requests/
erp-product-image-discovery-request.example.json: generic ERP/PIM template without image/source URLs.nike-air-force-1-live.json: concrete Nike smoke-test payload.herno-cappa-nylon-ultralight-cammello.json: concrete Herno fashion payload for live discovery/debug flow testing.
Nike Air Force 1 07, White/White
Source page: Nike Air Force 1 07 men's shoes
{
"client_id": 1,
"erp_model_id": "NIKE-AF1-07",
"erp_model_color_id": "NIKE-AF1-07-CW2288-111",
"brand": "Nike",
"supplier": "Nike",
"supplier_sku": "CW2288-111",
"model_code": "Air Force 1 07",
"color_code": "CW2288-111",
"color_name": "White",
"category": "Sneakers",
"material": "Leather"
}
Nike Air Force 1 07, White/White, LuisaViaRoma item
Source page: LuisaViaRoma Nike Air Force 1 07 sneakers
{
"client_id": 1,
"erp_model_id": "NIKE-AF1-07-WOMEN",
"erp_model_color_id": "LVR-82I-U3C014",
"brand": "Nike",
"supplier": "LuisaViaRoma",
"supplier_sku": "82I-U3C014",
"model_code": "Air Force 1 07",
"color_code": "82I-U3C014",
"color_name": "White",
"category": "Sneakers",
"material": "Calf leather"
}
adidas Originals Samba OG, White/Black, LuisaViaRoma item
Source page: LuisaViaRoma adidas Originals Samba OG sneakers
{
"client_id": 1,
"erp_model_id": "ADIDAS-SAMBA-OG",
"erp_model_color_id": "LVR-80I-T57018",
"brand": "adidas Originals",
"supplier": "LuisaViaRoma",
"supplier_sku": "80I-T57018",
"model_code": "Samba OG",
"color_code": "80I-T57018",
"color_name": "White/Black",
"category": "Sneakers",
"material": "Calf leather"
}
New Balance 550, White/Grey, LuisaViaRoma item
Source page: LuisaViaRoma New Balance 550 sneakers
{
"client_id": 1,
"erp_model_id": "NEW-BALANCE-550",
"erp_model_color_id": "LVR-78I-AM9016",
"brand": "New Balance",
"supplier": "LuisaViaRoma",
"supplier_sku": "78I-AM9016",
"model_code": "550",
"color_code": "78I-AM9016",
"color_name": "White/Grey",
"category": "Sneakers",
"material": "Leather and synthetic"
}
Amazon is not used as a default example because product pages are highly personalized, protected and terms-sensitive. Use official brand pages or trusted fashion retailers first.
Configuration
The main config file is config/product-image-discovery.php.
Important options:
route_prefix: defaultapi/product-image-discovery.route_middleware: default['api', 'auth:sanctum'].abilities: Sanctum ability names used by the package middleware.models: override Eloquent models if your app extends package models.jobs.ingest: override the entry job if you need custom orchestration.queues: queue names per pipeline phase.storage.disk: disk used for candidate assets.defaults: search, quality and decision thresholds.
Trusted Sources
Trusted source records let you prefer domains that are known to publish correct product images for a client or brand. A trusted source should improve confidence, but it should not bypass hard checks such as wrong color, wrong model, placeholder image or low-quality asset.
Optional Playwright Sidecar
Some ecommerce pages render images only after JavaScript runs. The package keeps browser rendering out of PHP and delegates it to an optional Node sidecar.
Start the sidecar:
cd sidecar
npm install
npm start
Sidecar endpoints:
GET /healthPOST /render
Environment variables:
SIDECAR_HOST=127.0.0.1
SIDECAR_PORT=3100
SIDECAR_SHARED_SECRET=change-me
SIDECAR_DEFAULT_TIMEOUT_MS=15000
SIDECAR_MAX_TIMEOUT_MS=30000
The sidecar uses Playwright when available and falls back to static HTTP+HTML extraction when browser rendering is unavailable.
AI And Vision
The package includes an optional Laravel AI SDK integration for AI-assisted candidate verification. The core pipeline does not require an LLM: deterministic source/text/quality checks still run first, and AI output is stored as supporting evidence in ai_analysis.
This keeps local development, CI and production ingestion stable even when a model provider is unavailable.
The config defaults to Regolo through padosoft/laravel-ai-regolo, while still supporting OpenAI, Anthropic and OpenRouter as alternate Laravel AI providers. AI verification is disabled by default, so the core pipeline remains deterministic and offline-friendly until you opt in with credentials.
PRODUCT_IMAGE_DISCOVERY_AI_ENABLED=false PRODUCT_IMAGE_DISCOVERY_AI_PROVIDER=regolo PRODUCT_IMAGE_DISCOVERY_AI_TIMEOUT=45 PRODUCT_IMAGE_DISCOVERY_AI_FAIL_SILENTLY=true PRODUCT_IMAGE_DISCOVERY_AI_ATTACH_REMOTE_IMAGE=false PRODUCT_IMAGE_DISCOVERY_AI_VISION_MODEL= PRODUCT_IMAGE_DISCOVERY_AI_DESCRIPTION_MODEL=Llama-3.3-70B-Instruct REGOLO_API_KEY= REGOLO_URL=https://api.regolo.ai/v1 REGOLO_BASE_URL= OPENAI_API_KEY= OPENAI_URL=https://api.openai.com/v1 OPENAI_BASE_URL= ANTHROPIC_API_KEY= ANTHROPIC_URL=https://api.anthropic.com/v1 ANTHROPIC_BASE_URL= OPENROUTER_API_KEY= OPENROUTER_URL=https://openrouter.ai/api/v1 OPENROUTER_BASE_URL=
To enable AI verification:
PRODUCT_IMAGE_DISCOVERY_AI_ENABLED=true PRODUCT_IMAGE_DISCOVERY_AI_PROVIDER=regolo REGOLO_API_KEY=your-key REGOLO_URL=https://api.regolo.ai/v1 PRODUCT_IMAGE_DISCOVERY_AI_DESCRIPTION_MODEL=Llama-3.3-70B-Instruct
For Anthropic:
PRODUCT_IMAGE_DISCOVERY_AI_ENABLED=true PRODUCT_IMAGE_DISCOVERY_AI_PROVIDER=anthropic ANTHROPIC_API_KEY=your-key PRODUCT_IMAGE_DISCOVERY_AI_VISION_MODEL=claude-sonnet-4-5-20250929 PRODUCT_IMAGE_DISCOVERY_AI_DESCRIPTION_MODEL=claude-haiku-4-5-20251001
For OpenRouter:
PRODUCT_IMAGE_DISCOVERY_AI_ENABLED=true PRODUCT_IMAGE_DISCOVERY_AI_PROVIDER=openrouter OPENROUTER_API_KEY=your-key OPENROUTER_URL=https://openrouter.ai/api/v1 PRODUCT_IMAGE_DISCOVERY_AI_VISION_MODEL=your-openrouter-vision-model-id
By default, remote image attachments are disabled and the verifier sends product/candidate metadata only. Set PRODUCT_IMAGE_DISCOVERY_AI_ATTACH_REMOTE_IMAGE=true when you want the selected provider/model to inspect the candidate image URL directly. Keep this opt-in because not every provider/model supports remote image attachments.
Regolo is the package default because it gives Laravel applications an Italian/EU sovereign AI path through the same laravel/ai API. If you switch to Anthropic, OpenAI or OpenRouter, set model names supported by that provider.
Testing
Install PHP dependencies:
composer install
Run all PHP suites:
vendor/bin/phpunit --testsuite Unit,Feature,E2E
Run sidecar tests:
cd sidecar npm test
The current local verification used Herd PHP 8.4:
& 'C:\Users\lopad\.config\herd\bin\php84\php.exe' vendor\bin\phpunit --testsuite Unit,Feature,E2E
In a fresh offline environment, live sidecar/search/AI checks are skipped cleanly unless their credentials or URLs are provided. The current local verification with real BRAVE_SEARCH_API_KEY, real ANTHROPIC_API_KEY and remote AI image attachments enabled is:
72 tests, 319 assertions, 1 skipped
The skipped test is the live sidecar contract. Set SIDECAR_E2E_URL to test against a real running sidecar. Live search and AI checks require their provider credentials.
Run the live AI verifier explicitly when you have a real Regolo, Anthropic, OpenRouter or OpenAI key in .env:
& 'C:\Users\lopad\.config\herd\bin\php84\php.exe' vendor\bin\phpunit --testsuite E2E --filter LiveProductImageAiVerifierTest
With PRODUCT_IMAGE_DISCOVERY_AI_ATTACH_REMOTE_IMAGE=true, this live test sends a real product image URL to the provider and should pass with 1 test, 9 assertions.
Database Tables
product_image_discovery_requestsproduct_image_discovery_candidatesproduct_image_discovery_source_pagesproduct_image_discovery_settingsproduct_image_trusted_sourcesproduct_image_search_providersproduct_image_discovery_events
Safety Notes
- Use the package only for lawful, authorized discovery activity and only on sources you are allowed to access.
- Respect robots.txt and source terms.
- Prefer official supplier, brand or trusted retailer sources.
- Do not publish images when license, ownership or product correctness is unclear.
- Keep manual review in the flow for uncertain matches.
- Treat watermarks, text overlays, placeholders and low-resolution images as quality risks.
Admin UI Guidance
This package stays headless. If you want to integrate a review/configuration experience inside an existing ecommerce admin, use docs/ADMIN_UI_UX_GUIDELINES.md. It describes the recommended vanilla JavaScript screens, components, filters, debug report viewer, guided debug-flow runner, provider credential status and API calls.
Roadmap
Recent additions (since v0.1.0):
- v1.0.0: search layer extracted into the standalone package
padosoft/laravel-ai-search-providers(Packagist v1.0.x). This repo now depends on it via composer; the existingProductImageSearchProviderEloquent model is preserved as a thin subclass for BC. - 8 live search providers wired through a single
SearchProviderManager:brave,tavily,exa,firecrawl,websearchapi,duckduckgo,searchapi,youcom. The drivers are maintained in the standalonepadosoft/laravel-ai-search-providerscomposer package (currently v1.2.x). Historical rollout is tracked in docs/ROADMAP_SEARCH_PROVIDERS.md. - Shared
AbstractHttpSearchProviderso new drivers add ~80 LOC of provider-specific code. - GitHub Actions CI for PHP 8.3 / 8.4 + Node sidecar.
- Junior-friendly Quick Start that brings a fresh Laravel 13 app to a successful API response in 5 minutes without external keys.
- Optional Regolo, Anthropic, OpenAI and OpenRouter providers for AI-assisted candidate verification.
- EAN / GTIN / barcode alias normalization with strong-match scoring.
Planned:
- First-party SerpAPI and Google Custom Search drivers (templates already seeded).
- Richer AI review signals while keeping deterministic checks as the publication gate.
- Perceptual-hashing duplicate detection.
- Image enhancement pipeline behind explicit config.
- Host-admin UI integration examples (sister repo:
padosoft/product_image_discovery_admin). - Runtime enforcement of
rate_limit_per_minute(currently advisory only).
Contributing
Pull requests are welcome. Before opening one:
- Keep changes focused.
- Add or update tests for behavior changes.
- Run the PHP suite.
- Run the sidecar suite if you touched
sidecar/. - Update docs when behavior, configuration or architecture changes.
License & credits
Apache-2.0. See LICENSE.
Sister packages in the Padosoft AI stack:
padosoft/laravel-ai-regolo-- first-class Regolo (Italian sovereign AI) provider forlaravel/ai.padosoft/laravel-flow-- saga / workflow orchestration for Laravel.padosoft/eval-harness-- RAG + agent evaluation harness.padosoft/laravel-pii-redactor-- PII redaction middleware for AI prompts.
Each is independently usable. None requires the others. Pick what you need.
