SugarBits

sugar-bits — 17 TUI components for PHP 8.3+: 9 first-party components (Table, Tabs, Tree, Progress, Paginator, Help, Key, Timer, Stopwatch) and 8 deprecated alias re-exports from sugarcraft/candy-forms (TextInput, TextArea, Viewport, Cursor, ItemList, FilePicker, Scrollbar, Spinner), including the interactive Tree and per-cell Table::styleFunc(...).

composer require sugarcraft/sugar-bits

TextInput, TextArea, and Help expose short-form aliases for the most-used setters: placeholder / charLimit / width / height / prompt / validator / styles / separator / ellipsis. The with* long forms still work side-by-side.

Components

9 first-party components: Help, Key, Progress (includes AnimatedProgress spring-variant), Timer, Stopwatch, Paginator, Tree, Table, Tabs — plus two btop-derived render helpers, Input\TextEdit and Menu\OptionRow. 8 deprecated alias re-exports from sugarcraft/candy-forms: Cursor, TextInput, TextArea, Viewport, ItemList, FilePicker, Scrollbar, Spinner.

Component	What it does	Notable msgs
`Cursor\Cursor`	Animated text cursor (deprecated alias — re-exported from `SugarCraft\Forms\Cursor`)	`BlinkMsg`
`Help\Help`	Render short / full key-help footer from a `KeyMap`; `Help::updateWithBinding($msg, $toggle)` flips show-all in response to a key	—
`Key\Binding`	One key + label + help row; `Binding::new(...)`, `Binding::withDisabled(...)` factories	—
`Spinner\Spinner`	Animated loading glyph — 12 built-in styles (deprecated alias — re-exported from `SugarCraft\Forms\Spinner` in `sugarcraft/candy-forms`)	`Spinner\TickMsg`
`Progress\Progress`	Static progress bar (gradient fill optional, `withColors(...)` / `withColorFunc(...)` / `withShowValue(...)`)	—
`Progress\AnimatedProgress`	Spring-physics-animated progress bar (HoneyBounce-driven)	`SpringTickMsg`
`Timer\Timer`	Countdown timer; `interval()`, `timeout()`, `withInterval(float)`	`Timer\TickMsg`, `TimeoutMsg`
`Stopwatch\Stopwatch`	Elapsed-time counter; `interval()`, `withInterval(float)`	`Stopwatch\TickMsg`
`TextInput\TextInput`	Single-line input with autocomplete + validators + `ValidateOn` timing + restrict pattern + vim mode + placeholder styling + prefix/suffix + `Styles` (deprecated alias — re-exported from `SugarCraft\Forms\TextInput`)	—
`TextArea\TextArea`	Multi-line editor with line numbers / set-prompt-func / `focused()` / `cursor()` / `line()` / `column()`; `Ctrl+O` opens the buffer in `$EDITOR` (`withEditorExtension('.md')` to control the syntax-highlight suffix) (deprecated alias — re-exported from `SugarCraft\Forms\TextArea`)	`TextArea\TextAreaEditedMsg`
`Viewport\Viewport`	Scrollable text region with mouse-wheel, scrollbar, horizontal scroll, `setWidth(int)` / `setHeight(int)` (deprecated alias — re-exported from `SugarCraft\Forms\Viewport`)	—
`Paginator\Paginator`	Dot / arabic page indicator	—
`ItemList\ItemList`	Selectable / scrollable / filterable list with status messages (deprecated alias — re-exported from `SugarCraft\Forms\ItemList`)	—
`Tree\Tree`	Interactive tree — cursor, expand/collapse, viewport scroll.	—
`Table\Table`	Selectable data table with `Column` struct + nav + multi-column sort	—
`Tabs\Tabs`	Tabbed panel — keyboard (`Tab`/`Shift+Tab`/`1-9`) + mouse navigation, wrap/clamp modes, scrollable overflow	—
`FilePicker\FilePicker`	Directory browser with icons / size / sort modes (deprecated alias — re-exported from `SugarCraft\Forms\FilePicker`)	—
`Scrollbar\Scrollbar`	Scrollbar indicator for scrollable viewports (deprecated alias — re-exported from `SugarCraft\Forms\Scrollbar`)	—
`Input\TextEdit`	Inline single-line editor value object with an underline caret (no hardware cursor), grapheme-cluster caret, cell-budget windowing, digits-only mode — btop `Draw::TextEdit`	—
`Menu\OptionRow`	Static renderer for btop's two-line options-menu row (bold centred name + `← value →` / `↵` line, live `TextEdit` while editing)	—

Vim mode

TextInput vim mode (Insert/Normal/Visual/VisualLine keybindings) is powered by candy-forms's shared VimKeyHandler — the same handler backing sugar-prompt and sugar-readline. Adding a new binding to the VimAction enum benefits all three libs at once. The per-lib opt-in flag withVimMode(true) is preserved; consumers control whether vim mode is enabled.

Msg routing cheat-sheet

Forward these into your model's update() so the embedded component can react: BlinkMsg (Cursor / TextInput), Spinner\TickMsg (Spinner), Timer\TickMsg + Timer\TimeoutMsg, Stopwatch\TickMsg, SpringTickMsg (AnimatedProgress), StartStopMsg (Timer / Stopwatch), TextArea\TextAreaEditedMsg (TextArea's Ctrl+O round-trip). Each component's update() filters by its own id() so multiple instances of the same component coexist on one event loop.

Quickstart — TextInput with autocomplete

use SugarCraft\Bits\TextInput\TextInput;
use SugarCraft\Core\{Cmd, Model, Msg, Program};
use SugarCraft\Core\Msg\KeyMsg;
use SugarCraft\Core\KeyType;

final class Search implements Model
{
    public function __construct(public readonly TextInput $ti) {}

    public function init(): ?\Closure { return null; }

    public function update(Msg $msg): array
    {
        if ($msg instanceof KeyMsg && $msg->type === KeyType::Enter) {
            return [$this, Cmd::quit()];
        }
        if ($msg instanceof KeyMsg && $msg->type === KeyType::Tab) {
            return [new self($this->ti->acceptSuggestion()), null];
        }
        [$ti, $cmd] = $this->ti->update($msg);
        return [new self($ti), $cmd];
    }

    public function view(): string
    {
        $body = $this->ti->view();
        if (($s = $this->ti->currentSuggestion()) !== null) {
            $body .= "\n  → $s";
        }
        return $body;
    }

    public function subscriptions(): ?\SugarCraft\Core\Subscriptions
    {
        return null;
    }
}

[$ti, $cmd] = TextInput::new()
    ->withSuggestions(['apple', 'apricot', 'banana', 'cherry'])
    ->showSuggestions()
    ->withValidator(fn(string $v) => strlen($v) >= 2 ? null : 'too short')
    ->focus();

(new Program(new Search($ti)))->run();

Quickstart — animated progress bar

use SugarCraft\Bits\Progress\AnimatedProgress;

$bar = AnimatedProgress::new()
    ->withWidth(40)
    ->withDefaultGradient();

[$bar, $cmd] = $bar->setPercent(0.75);
// dispatch $cmd via the Program — ticks re-fire from inside update()
// until the bar settles within 5e-4 of the target.

Quickstart — TextInput with placeholder styling and prefix/suffix

use SugarCraft\Bits\TextInput\TextInput;
use SugarCraft\Sprinkles\Style;
use SugarCraft\Core\Util\Color;

$ti = TextInput::new()
    ->withPlaceholder('Enter command…')
    ->withPlaceholderStyle(Style::new()->faint())           // default: dim
    ->withPrefix('$ ')                                      // fixed prefix
    ->withSuffix(' <');                                     // fixed suffix

echo $ti->view();
// $ Enter command… <

TextInput — ValidateOn and restrict

TextInput supports deferred and filtered validation via two new builders:

ValidateOn timing control

use SugarCraft\Bits\TextInput\{TextInput, ValidateOn};

$ti = TextInput::new()
    ->withValidateOn(ValidateOn::Blur);   // validate when focus leaves

Case	When validation fires
`ValidateOn::None`	Never (default — use when you drive validation manually)
`ValidateOn::Blur`	When the input loses focus
`ValidateOn::Change`	On every keystroke
`ValidateOn::Submit`	Only on `Enter` keypress

Keystroke filter (restrict)

use SugarCraft\Bits\TextInput\TextInput;

// Accept only digits
$numeric = TextInput::new()->withRestrict('[0-9]');

// Accept alphanumeric only
$alphanum = TextInput::new()->withRestrict('[a-zA-Z0-9]');

TextInput notable builders

Method	What it does
`withValidateOn(ValidateOn $timing)`	Set validation timing (`None` / `Blur` / `Change` / `Submit`)
`withRestrict(string $pattern)`	Set a PCRE regex — only matching characters are accepted (no delimiters)

Table — multi-column sort

use SugarCraft\Bits\Table\{Table, SortDirection, SortState};

// Primary sort by Name ascending
$t = $table->withSort('Name');

// Tiebreaker: Age descending
$t = $table->thenSortBy('Age', SortDirection::Desc);

// Reset to insertion order
$t = $table->clearSort();

// Inspect current sort criteria
$state = $t->sortState(); // SortState
foreach ($state->criteria as [$colIndex, $dir]) {
    // $colIndex is an int, $dir is SortDirection::Asc or SortDirection::Desc
}

SortDirection enum

Case	Value	Description
`SortDirection::Asc`	`'asc'`	Sort in ascending order
`SortDirection::Desc`	`'desc'`	Sort in descending order

SortDirection::toggle() returns the opposite direction.

SortState DTO

Immutable list of sort criteria — each entry is a (column index, direction) pair. Applied in order: first entry is primary sort, second is tiebreaker, etc.

Method	Returns	Description
`SortState::empty()`	`SortState`	Factory for no criteria
`SortState->withCriterion(int $col, SortDirection $dir)`	`SortState`	Append a criterion
`SortState->isEmpty()`	`bool`	True when no criteria are set
`SortState->criteria`	`list<array{0:int,1:SortDirection}>`	Raw criteria list

Table sort builders

Method	Description
`withSort(string $column, SortDirection $dir = Asc)`	Set primary sort — clears any prior sort chain
`thenSortBy(string $column, SortDirection $dir = Asc)`	Add a secondary (or further) tiebreaker criterion
`clearSort()`	Remove all sort criteria, restoring insertion order
`sortState(): SortState`	Return the current sort criteria (readonly accessor)

Sorting throws \InvalidArgumentException with message table.sort_unknown_column when the column name is not found. The exception message is localizable.

Table — filtering

use SugarCraft\Bits\Table\Table;

// Enable the filter feature (opt-in)
$t = $table->withFilterable(true);

// Set a query string — default: case-insensitive substring match across all visible columns
$t = $table->withFilter('foo');

// Custom filter: receives a row (list<string>), returns true to keep
$t = $table->withFilterPredicate(fn(array $row): bool =>
    str_contains(strtolower(implode("\t", $row)), 'foo')
);

// Inspect current filter state
$isFilterable = $t->filterable();   // bool
$query        = $t->filter();        // string
$predicate    = $t->filterPredicate(); // ?Closure(list<string>): bool

When withFilterPredicate() is set, it overrides the default substring-match behaviour. Pass null to restore the default.

Table filter builders

Method	Description
`withFilterable(bool $filterable)`	Enable or disable the filter feature
`withFilter(string $query)`	Set the filter query string (non-empty enables filtering)
`withFilterPredicate(?Closure(list<string>): bool $predicate)`	Custom filter callable — `null` restores the default
`filterable(): bool`	Return whether filtering is enabled
`filter(): string`	Return the current filter query string
`filterPredicate(): ?Closure`	Return the current custom predicate

The default filter applies case-insensitive substring matching across all visible columns.

Table — pagination

use SugarCraft\Bits\Table\Table;

// Enable pagination: 10 rows per page
$t = $table->withPageSize(10);

// Navigate pages
$t = $t->withPage(1);   // zero-based — go to page 1 (second page)
$t = $t->nextPage();
$t = $t->prevPage();
$t = $t->pageFirst();
$t = $t->pageLast();

// Inspect pagination state
$pageSize   = $t->pageSize();      // int — rows per page (0 = pagination disabled)
$current   = $t->currentPage();   // int — zero-based current page
$totalPages = $t->paginator()->totalPages();  // int — 1 when pagination is disabled

// Wire a Paginator to the table for UI rendering
$paginator = $t->paginator();    // Paginator instance

Table pagination builders

Method	Description
`withPageSize(int $size)`	Set rows per page — `0` disables pagination; `≥1` enables it
`withPage(int $page)`	Navigate to a zero-based page (clamps to valid range)
`nextPage()`	Advance one page
`prevPage()`	Retreat one page
`pageFirst()`	Jump to the first page
`pageLast()`	Jump to the last page
`pageSize(): int`	Return rows per page (`0` = pagination off)
`currentPage(): int`	Return the current zero-based page
`paginator()->totalPages(): int`	Return the total page count (`1` when pagination is disabled)
`paginator(): Paginator`	Return a `Paginator` instance wired to the table's current page state

Pagination works with sort and filter: changing the sort order, filter query, or page size automatically re-clamps the cursor to the first row of the current page so the cursor never points to a row outside the current page boundary.

btop helpers — TextEdit, OptionRow, position-coloured Progress

Three pieces added for candy-top (the btop-inspired system monitor) that are useful to any TUI drawing overlays, option screens or gradient meters.

`Input\TextEdit` — underline-caret inline editor

A pure immutable value object (not a Model–Update–View component) mirroring btop Draw::TextEdit — the proc filter bar and options-menu value editor. The caret is drawn as an SGR underline (TextEdit::UL / TextEdit::UUL) on the cluster under it, so several editors can be on screen while the hardware cursor stays hidden. For a focusable, blinking, validated input use TextInput instead.

use SugarCraft\Bits\Input\TextEdit;

$edit = TextEdit::new('firefox')   // caret defaults to the end
    ->home()->right()->right()     // caret on "r"
    ->insert('X')                  // "fiXrefox"
    ->backspace();                 // "firefox", caret 2
echo $edit->view();                // "fi\e[4mr\e[24mefox"
echo TextEdit::new('a-very-long-filter-string')->view(10); // "er-string\e[4m \e[24m"

$pid = TextEdit::new('', numeric: true)->insert('12')->insert('a')->insert('3');
echo $pid->text();                 // "123" — non-digit input is rejected whole

new(string $text = '', ?int $caret = null, bool $numeric = false); accessors text() / caret() / numeric() / length().
Editing: left() / right() / home() / end() / withCaret(int) (clamped) / insert(string) / backspace() / delete() / clear().
The caret counts grapheme clusters (a ZWJ emoji or combining sequence moves and deletes as one); view(int $limit = 0) budgets in display cells, windowing around the caret with btop's half-budget law. Unlike btop, the end-caret cell is charged to the budget, so output never exceeds $limit. $limit <= 0 is unlimited.
withNumeric(bool $on = true) strips existing non-digits (keeping the caret on the same surviving digit) so text() is always parseable.

`Menu\OptionRow` — btop options-menu geometry

OptionRow::render(...) returns the two-line row from btop Menu::optionsMenu: line 1 the bold name centred in $nameCol (default OptionRow::NAME_COL = 29), line 2 " " + value centred in $valueCol (VALUE_COL = 25) + " ", with ← / → on the selected row (while not editing) when $hasArrows and ↵ (or E with tty: true) when $editable. Passing a TextEdit with editing: true renders its underline-caret view in valueCol - 1 cells.

use SugarCraft\Bits\Input\TextEdit;
use SugarCraft\Bits\Menu\OptionRow;
use SugarCraft\Core\Util\Color;
use SugarCraft\Sprinkles\Style;

echo OptionRow::render(
    'Update ms',
    TextEdit::new('2000', numeric: true),
    selected: true,
    editing: true,
    hasArrows: true,
    editable: true,
    selBg: Style::new()->background(Color::hex('#3d59a1')),
    selFg: Style::new()->foreground(Color::hex('#ffffff')),
);

Centering follows btop cjust (the odd spare column goes on the left, the opposite of Width::padCenter()); over-wide text truncates to the column in display cells. The selected style deliberately bleeds into the value line, so the selected option reads as one two-row block. Optional title: / main: styles colour the unselected name / value.

`Progress::withColorFunc` — bar width as a 4th argument

The colour closure is now called fn(int $i, int $filledCells, float $percent, int $barWidth): Color — $barWidth is the true cell width (filled + empty, after any percent suffix). That lets each filled cell take its colour from its position on a 101-stop ramp, btop-style. Three-parameter closures keep working.

use SugarCraft\Bits\Progress\Progress;
use SugarCraft\Core\Util\Color;

$ramp = Color::hex('#50fa7b')->blend1d(Color::hex('#ff5555'), 101);
echo Progress::new()
    ->withWidth(20)
    ->withShowPercent(false)
    ->withPercent(0.6)
    ->withColorFunc(static fn (int $i, int $filled, float $pct, int $barWidth): Color
        => $ramp[(int) round(($i + 1) * 100 / $barWidth)])
    ->view();

This gives btop's colouring, not its fill count (Progress fills round(percent * width) cells). For an exact btop meter use sugar-dash Meter::withGradient($stops, positionWise: true).

Snapshot tests

Render output is covered by golden-file snapshot tests. Fixture files live in tests/fixtures/ with a .golden extension and are compared against actual ANSI byte output via SugarCraft\Testing\Snapshot\Assertions::assertGoldenAnsi(). To re-record fixtures after intentional output changes:

UPDATE_GOLDENS=1 vendor/bin/phpunit

Test

cd sugar-bits && composer install && vendor/bin/phpunit

Demos

Cursor

File picker

Help

Item list

Paginator

Progress

Spinners

Stopwatch

Tabs

Table

Text area

Text input

Text input (enhanced)

Timer

Tree

Viewport

SugarCraft monorepo

Credits & inspiration

Originally inspired by the Go Charm ecosystem; SugarCraft is developed as a native PHP project.

sugarcraft / sugar-bits

Package info

Security

Statistics
