README

A full-screen terminal system monitor for PHP 8.3+, built on the SugarCraft TUI stack. candy-top shows live CPU, memory, disk, network, process and container panels with braille, block or sextant graphs, gradient meters and themes in the btop tradition, and follows the feature set of aristocratos/btop v1.4.7 plus a set of adopted upstream pull requests. Everything runs on the candy-core Model/Cmd runtime, and the drawing uses sugar-dash, sugar-bits and candy-sprinkles.

candy-top reads btop's config format and btop's .theme files, and its keys, menus and layout rules follow btop's source. Where it differs from btop, the Differences from btop section says so.

Contents

• Requirements
• Install
• Run
• The boxes
• Menus and overlays
• Presets
• Key bindings
• Mouse
• Configuration
• Config keys
• Themes
• TTY mode
• Data sources and permissions
• Containers and VMs
• GPU
• Adopted upstream btop PRs
• Differences from btop
• Development

Requirements

• PHP 8.3 or newer, CLI.
• A terminal with an interactive tty on both stdin and stdout. Like btop, candy-top refuses to start without one ("No tty detected!").
• Truecolor is recommended. With truecolor = false colours are mapped to the 256-colour cube, and in TTY mode the 16 terminal colours are used.
• Optional PHP extensions:
  • ext-posix shows user names in the process list (otherwise numeric uids), sends signals (posix_kill) and detects a real console (posix_ttyname).
  • ext-pcntl renices processes (pcntl_setpriority; PHP's proc_nice() cannot renice another pid) and traps SIGTERM/SIGHUP so the config is still saved.
• Optional: nvidia-smi for NVIDIA GPU readings. AMD and Intel GPUs and Intel/AMD NPUs are read from sysfs on Linux and need no extra tools.

Install

composer require sugarcraft/candy-top

Add :@dev (composer require sugarcraft/candy-top:@dev) while your project's minimum-stability is stable and no tagged release exists. Composer installs the launcher as vendor/bin/candy-top. For a global tool, use composer global require sugarcraft/candy-top and put Composer's global vendor/bin on your PATH.

Run

vendor/bin/candy-top                     # live host, default config
vendor/bin/candy-top --config ~/top.conf # another config file (also the save target)
vendor/bin/candy-top --fake              # deterministic demo data, never the real host
vendor/bin/candy-top --help              # options plus the full key list

Flag	Effect
--fake	Uses the seeded fake collectors (Source\Fake\*) instead of the live host. The data is deterministic and the pids are invented, so it suits demos and VHS tapes. The fake host has two GPUs and one NPU (gpu boxes gpu0-gpu2), with per-process GPU use.
--config <path>, --config=<path>	Reads the config from <path> instead of $XDG_CONFIG_HOME/candy-top/config.conf. That file is also where the config is saved. A missing value is an error (exit 2). So is a following argument that starts with - in the space-separated form (--config -x); --config=-x is accepted as a path.
-h, --help	Prints usage and the KEYS section, which is generated from the same key table as the help overlay, then exits 0. Works without a tty.

Any other argument exits with status 2. There is no --tty flag. TTY mode comes from the force_tty option or from running on a real console, as described in TTY mode. Config load warnings (bad values) are printed on stderr at startup, and the option keeps its default.

From a monorepo checkout, php candy-top/bin/candy-top works as well. php candy-top/examples/top.php runs the fake demo with a throwaway config path. The VHS tape candy-top/.vhs/top.tape records that demo.

The boxes

The screen is split into four boxes, plus the containers box, up to six gpu boxes, the VM dashboard and the BMC box, laid out by a PHP re-implementation of btop's calcSizes. Keys 1 to 4 toggle the four boxes, x toggles the containers box, v toggles the VM dashboard (which takes the area below the cpu box), I (shift + i) toggles the ipmi band under the cpu box, keys 5 to 0 toggle gpu box slots, and the shown_boxes option sets which are shown. Placement flags move the boxes around: cpu_bottom puts cpu at the bottom, mem_below_net swaps mem and net, proc_left moves proc to the left, and proc_box_width_percent sets the proc width. Box titles and buttons are drawn into the borders, and each button's hotkey letter is highlighted. A clock (clock_format) sits in the top border. When the terminal is smaller than the layout's minimum, btop's "Terminal size too small" notice is shown instead. q, 1 to 4 and the gpu slot keys 5 to 0 still work behind that notice (x does not, as in btop #1873).

Hidden boxes are never sampled or drawn (btop #1858). Every graph dimension is clamped to at least 1 cell, so even odd layouts cannot crash a graph.

cpu

• Upper and lower graphs. These are dual-sample graphs (graph_symbol_cpu) showing the fields picked by cpu_graph_upper and cpu_graph_lower (total, user, system, iowait, steal, and the other /proc/stat columns, plus the GPU fields described below). A divider row such as total─▲▼─user separates them. cpu_invert_lower inverts the lower graph, and cpu_single_graph turns it off.
• Per-core grid. Each core gets a mini graph on a dimmed underlay, its percentage, and its temperature when show_coretemp is on. Cores that have never reported are dimmed. A position-coloured meter row shows the total.
• Frequency. The title shows the frequency when show_cpu_freq is on, collapsed by freq_mode (first, range, lowest, highest, average). show_core_freq (btop #1785) adds a per-core value (value) or a mini history graph (graph) to each core. When a column is too narrow for the extra cells, it falls back from graph to value to off rather than overflowing.
• Temperature. check_temp, cpu_sensor (choose from a list in the options menu), show_coretemp, cpu_core_map and temp_scale (celsius, fahrenheit, kelvin, rankine) control the temperature readings.
• Load, uptime and the - 2000ms + button. The footer shows load averages and the uptime (show_uptime). The update-interval button in the border steps update_ms.
• Battery. A badge in the top border shows the percentage, a charge meter, the status, time to empty or full, and the draw in watts (show_battery_watts). It appears only when show_battery is on and a battery is present. selected_battery chooses between several batteries, and the clock makes room for the badge.
• GPU sub-graphs. These appear when a GPU answers and show_gpu_info is On, or Auto while some GPU has no gpu box of its own (btop #1730). Under Auto the cpu box lists only the GPUs without a box; On lists every GPU. With cpu_graph_lower = Auto, the lower graph becomes gpu-totals, one graph per listed GPU separated by a divider column, with widths split as in btop #1614. The other choices are gpu-vram-totals and gpu-pwr-totals (one graph per GPU), and gpu-average, gpu-vram-total and gpu-pwr-total (one shared graph). The cores box also lists a brief row for each listed GPU. NPUs never appear in the cpu box. The cpu box keeps sampling the GPUs while cpu_graph_upper or cpu_graph_lower names a gpu-* field, even when every GPU has its own box. See GPU.

mem

• Memory. Shows used, available, cached and free, either as graphs (mem_graphs, the default) or as meters. mem_selected (btop #1747) focuses on a single metric (used, available, cached, free or swap_used) and draws it as one large graph with the percentage overlaid.
• Swap. show_swap shows swap figures. show_zswap (btop #1739, Linux 5.19+) adds a zswap row, and swap Used then counts only the pages actually on disk.
• Disks. When show_disks is on (d toggles it), the right part of the box lists the mounts. Each mount shows used and free meters, read and write rates, and a busy-percentage graph (show_io_stat). / comes first, then the swap pseudo-disk (swap_disk), then the order of the mount table. disks_order (btop #1700) puts named mounts, or swap, first. disks_filter selects mounts (prefix the list with exclude= to invert it). use_fstab, only_physical and zfs_hide_datasets filter further.
• IO mode. i toggles io_mode, which draws large read and write graphs per disk, mirrored or combined (io_graph_combined). Each disk is scaled to io_graph_speeds (MiB/s per mount point).
• ZFS. With zfs_arc_cached, the ARC counts as cached memory, and as available memory above its minimum size.

net

• Graphs. Download and upload graphs for the selected interface, plus a stats sub-box with the current rate, the top rate and the total for each direction. swap_upload_download puts upload on top.
• Auto-scale. net_auto, toggled by a, rescales the graphs with hysteresis (sugar-dash NetAutoScale), never going below 10 KiB. net_sync, toggled by y, gives both directions the same scale. With auto-scale off, net_download and net_upload set fixed ceilings in Mebibits. Toggling either option rescales at once.
• Interface selection. At startup the interface is net_iface if it exists. Otherwise the first connected interface with the most traffic is picked, and that pick sticks until the interface disappears. b and n cycle through the interfaces. That choice is not saved.
• Zeroing. z resets the totals of the current interface, and a second z restores them.
• Addresses. The interface's IPv4 address (otherwise its global IPv6 address) is shown in the title (btop #1573). net_hide_ip hides it.
• Bitrate units. base_10_bitrate (Auto follows base_10_sizes).

proc

• List. Columns are pid, program, command, threads, user, memory, cpu% and a per-process mini cpu graph (proc_cpu_graphs). The colours come from the cpu gradient (proc_colors), with a darkening fade away from the selection (proc_gradient). When the box is at least 90 columns wide, IO/R and IO/W columns are added (btop #1823). /proc/[pid]/io is sampled while those columns show or an io * sort is active, so the io sorts also work in a narrower box, where the columns stay hidden. A process whose io file is unreadable shows -, never 0.
• GPU columns (btop #1552). Once per-process GPU data has been measured on the host, the box adds Gpu% (GPU utilisation, summed over the process's GPUs and clamped to 100), a per-process mini GPU graph (proc_gpu_graphs, on by default) and GMem (GPU memory). They need room: with both mini graphs on, Gpu% and its graph appear from 86 columns and GMem from 92. Turning proc_gpu_graphs or proc_cpu_graphs off lowers each threshold by 5 (81/87), and turning both off by 10. While GPU data is measured the IO columns yield to them and need 106 columns (101 with one mini graph off, 96 with both off) instead of 90. Per-process data comes from nvidia-smi --query-compute-apps plus nvidia-smi pmon on NVIDIA and from DRM fdinfo on amdgpu, i915 and xe; it is held between GPU samples, and a pid the GPU sample no longer lists reads 0. It is collected only while a Gpu% column fits, proc_gpu_only is on, or a gpu sort is active.
• Sorting. ← and → cycle through pid, name, command, threads, user, memory, cpu direct, cpu lazy, io read, io write, io total, gpu and gpu memory. r reverses the order. cpu lazy is btop's smoothed sort, which pulls hogs forward over time. The two gpu sorts (btop #1552) sort by per-process GPU utilisation and GPU memory.
• Tree view. e turns on the tree view. Space or +/- collapses or expands the selected branch, C collapses or expands its children, and E does all branches. proc_aggregate adds child usage, GPU use included, to the parent. proc_tree_auto_collapse collapses wide branches on entry. Siblings are sorted by branch totals (btop #1791a).
• Filter. f or / starts a live filter. A plain filter is a case-insensitive substring of the pid, name, command, user or container/VM name. A filter starting with ! is a regular expression, searched in the pid, name and user and fully matched against the command. Enter keeps the filter, Esc restores the previous one, and delete clears it. proc_filter_kernel hides kernel threads. proc_filter_containers, toggled by O, hides processes in containers and VMs.
• GPU-only filter (btop #1552). proc_gpu_only shows only processes with non-zero GPU utilisation or GPU memory. g toggles it, as does ctrl+g and the gpu-only button in the box title. With vim_keys, g stays "top of list", so use ctrl+g. The filter and the button apply only once per-process GPU data has been measured; on a host without it the option is inert. In the tree view a GPU-idle process is hidden the way a non-matching text filter hides it.
• Other display options. c switches to per-core cpu% (proc_per_core). % switches memory between bytes and percent (proc_mem_bytes). proc_command_basename (btop #1859) shows only the executable's basename in the list.
• Detailed view. Enter on a selected row opens a detail pane with the status, elapsed time, parent, user, threads, nice, memory, IO totals, cwd (btop #1546) and the full command. Enter again closes it. With proc_follow_detailed on, the list follows the detailed process.
• Signals. Each of these acts on the selected row, or on the detailed process when no row is selected. t asks for confirmation, then sends SIGTERM. k asks for confirmation, then sends SIGKILL (K with vim_keys). s opens the signal chooser and N opens the renice menu. A failure (EPERM, ESRCH, ...) opens an error box.
• Follow and pause. F keeps the selected process centred as the list re-sorts, and u pauses list updates (pause_proc_list). While either is active, a banner sits on the list's last row.
• Mouse. Click a row to select it, and click the selected row to open its detail view. Click the [-]/[+] marker to collapse or expand a branch. Clicking the scrollbar pages at the arrows, drags the thumb, or jumps proportionally. The wheel scrolls by 3 rows.
• Containers and VMs. These are tagged in the command column. See Containers and VMs.

ctr

The containers box (btop #1873) lists the containers that have processes running, one row each, and (unlike btop) the libvirt/KVM virtual machines too. x toggles it, as does the x ctr button on the cpu box's top border (shown when the cpu box is at least 76 columns wide), and ctr in shown_boxes or a preset turns it on.

• Engine in the title. When candy-top itself runs inside a container, the cpu box's top border shows the engine's name where the x ctr button would be, as btop does. The name is detected once at startup without starting any process. The checks run in this order: KUBERNETES_SERVICE_HOST (k8s), /run/.containerenv (podman), /.dockerenv (docker), the first word of /run/systemd/container, container= in /proc/1/environ, a container path in /proc/self/cgroup, and an overlay root mount in /proc/self/mountinfo whose layers are docker's, podman's or containerd's. systemd's names are shortened (systemd-nspawn to nspawn, lxc-libvirt to lxc). On FreeBSD a jail (security.jail.jailed) shows jail. The label is cut to fit before the clock. Clicking it, or pressing x, still toggles the box.

• Placement. The box sits at the top of the proc column and takes a third of it: at least 6 rows, and never so many that the proc box drops below 16. Without the proc box it takes the whole column. Its minimum size is 44x6.

• Rows. Each row shows the name (the docker name, the short id, or a VM's domain name), the engine (when the list is at least 52 columns wide), the process count, memory, a 5-cell cpu mini graph (graph_symbol_proc) and cpu%. The rows are sorted by name. Colours follow proc_colors. The bottom border shows selected/count.

• Selecting. [ and ] step through "no selection" and the containers, wrapping round. The halves of the [ select ] title button do the same, and clicking a row selects it or, if it is already selected, clears the selection. While a container is selected the proc box shows only that container's processes (in list and tree view) and its selection jumps back to the top. The selection is cleared when the container goes away or the box is hidden.

• Detail. With a container selected and the box at least 80 columns wide, a panel on the right shows its name and engine (and a VM's vCPU count), cpu%, a cpu history graph, and a memory meter against its memory.max. When that is unlimited, the meter uses a VM's configured memory, or else total memory. A VM's title also gives its cpu as a share of its own vCPUs (Cpu 7.5% · 15.0% of 4 vCPU); the list column stays a share of the host, as for containers.

• Figures. On cgroup v2, cpu is the cpu.stat usage_usec delta (percent of the whole machine, or of one core with proc_per_core). Memory is memory.current minus inactive_file, which is what docker stats shows. Where those files cannot be read (cgroup v1, or permissions) the box shows the sum of the container's processes instead. The cpu graph is always a percentage of total cpu power.

• Docker names. When a new docker container appears, one GET /containers/json is sent over the docker socket (/var/run/docker.sock, or DOCKER_HOST when it is a unix:// path), with a 1 s deadline. Without access to the socket the short id stays. A name, once found, is kept until the container restarts, so a docker rename shows after the restart.

• Cost. The box reads the proc box's process scan rather than scanning /proc itself; opening it beside the proc box makes the proc box rescan at once. It runs its own scan only while the proc box is hidden. A sample covering less than half of update_ms (a proc rescan after a sort change, Enter or a toggle) is skipped, so the cgroup cpu% always spans a real interval; re-showing the box resets that window, so its first sample always counts. A hidden box costs nothing, and on FreeBSD nothing is scanned for it.

• VMs. Each libvirt/KVM guest is one row with engine kvm, the same word as its [kvm:name] process tag. Its processes are grouped by the guest's machined scope (machine.slice/machine-qemu\x2d<id>\x2d<name>.scope; the qemu process itself sits in its libvirt/emulator child). The row is named by the domain name: the emulator's -name guest= value, or else the scope's name with the systemd \x2d escapes decoded. The figures are the scope's cgroup v2 files, read as for a container. A guest's memory.max is normally max, so its memory limit is the RAM it was started with (-m, read from its command line; libvirt is never called). memory.current does not count hugetlb pages, so a hugepage-backed guest reads low, and QEMU's own overhead can push a guest past its -m, in which case the meter stops at 100%. VMs sort, select and filter the proc box exactly like containers. ctr_show_vms = false leaves them out, as btop does. A bare qemu started outside libvirt owns no cgroup and is not listed.

• Not listed. Flatpak and Snap are not containers. On FreeBSD the box stays empty.

vms

The VM dashboard (candy-top's own; btop has none) shows every running libvirt/KVM guest as a card. v toggles it, as does the vms button on the cpu box's top border (shown on hosts running libvirt, right after x ctr, when the clock leaves room), and vms in shown_boxes or a preset turns it on.

• Layout. While shown, the dashboard takes everything below the cpu box (and the gpu boxes) and hides mem, net, proc and ctr. Those boxes stay in shown_boxes, so toggling the dashboard off brings back exactly the boxes that were showing. Hidden boxes are not sampled, and their minimum sizes do not count toward the size notice; the cpu box's GPU rows do, so the dashboard always has room for a row of cards. The cpu box shrinks to the height its cores need (from btop's minimum of 8 rows), giving the cards the rest. Pressing 2, 3, 4 or x while the dashboard is shown leaves it and shows that box, and v works behind the size notice too.
• Cards. Each card is titled with the domain name, its vCPUs and its configured RAM. The rows are:
  • CPU: a meter of the guest's share of its OWN vCPUs (100% = every vCPU busy; emulator and I/O threads can push the figure past 100) with a history graph;
  • RAM: the host-resident memory (memory.current minus inactive_file) against the configured RAM;
  • DSK: read ▲ / write ▼ rates with mini graphs;
  • NET: the guest's download ▼ / upload ▲ (its tap's tx / rx), with mini graphs. The columns follow the terminal width (34-column cards). When the whole fleet fits with room to spare, the cards grow to fill the box: a full-width cpu history first, then taller disk and net graphs, and from four spare rows a PSI cpu … mem … io … line. The colours are the other boxes' gradients, and every outline follows the theme's mem_box flow across the whole dashboard.
• Pressure. A guest whose worst PSI some avg10 (cpu.pressure, memory.pressure, io.pressure of its scope) reaches 10% gets a psi cpu 23% badge on its card, in the temp gradient. This flags a guest that is starved for cpu, memory or io, which no utilisation figure shows.
• Order and selection. Cards are sorted by vms_sorting (cpu by default, then mem, disk, net, psi, name); s / S or the halves of the sort ‹ cpu › button cycle it. The arrow keys move the selection through the grid, PgUp/PgDn move a page, and Home/End jump to the ends. The grid scrolls by rows to keep the selection in view; the bottom border shows the visible range (1-30/55) and the allocation summary (vCPUs given out against host cpus, configured RAM against MemTotal).
• Enter. Enter (or a click on the selected card) leaves the dashboard with the proc box filtered to that guest: proc and ctr are shown and the guest is picked in the ctr box (ctr_selected). With ctr_show_vms off the ctr box lists no guests, but the pick still filters the proc box (the option is not changed) and the ctr box's bottom border says proc filter: kvm:<guest>; the pick is dropped once the guest has no process left.
• Data. No subprocess and no libvirt connection. Guests are the machined scopes under /sys/fs/cgroup/machine.slice (and libvirt's own machine/ layout). vCPUs, RAM, the tap names and the qemu pid come from libvirt's live XML (/run/libvirt/qemu/<name>.xml, root only), re-read only when it changes. Without root, the facts come from the qemu command line (-smp, -m), the taps are matched by MAC (libvirt gives a tap its guest's MAC with the first octet fe, or fa when it already was fe; a macvtap keeps the guest MAC), and the bottom border says not root: no libvirt XML. Disk rates come from the qemu process's /proc/<pid>/io read_bytes/write_bytes (root). On a host whose images sit on ZFS or are written back by the kernel's flusher, the scope's io.stat reads near zero, so it is only the fallback (summed over devices, which double-counts stacked md/dm devices). The dashboard is sampled only while it is shown; on a 55-guest host a sample costs about 15 ms. After it has been hidden, the first sample starts the histories afresh instead of plotting the hidden period's average.
• Empty. A host without libvirt shows "No virtual machines found". FreeBSD always does: bhyve is not covered.

ipmi

The ipmi box (candy-top's own; btop has none) shows the machine's BMC — the baseboard management controller every server board carries — as read by ipmitool: the whole-system power draw, each power supply, fans, temperatures, voltages, the chassis fault flags and the System Event Log. I (shift + i; i is mem's io_mode) toggles it, as does the IPMI button on the cpu box's top border (shown on hosts with a BMC device node, after x ctr / vms, when the clock leaves room), and ipmi in shown_boxes or a preset turns it on.

• Layout. A full-width band directly under the cpu box (and the gpu boxes), 28% of the terminal height between 6 and 16 rows, never squeezing the boxes below it under their minimums; alone with cpu it takes the whole rest. It stays shown beside the VM dashboard (on a hypervisor, the BMC's power and thermals are the other half of the fleet picture), and its minimum (40×6) counts toward the size notice. The outline uses the net_box family and its flow: the band's neighbours are cpu above and mem, proc or the VM dashboard below, none of which is the net family.
• Detail levels. The box degrades by size, as the gpu boxes do:
  • full (64×14 or more, or 100×8 for a short band): titled sub-panels in 2, 3 or a 4-column strip (power | temperatures | fans + voltages | status), whichever leaves the least blank space;
  • compact (34×6): the power gauge beside the hottest temperatures, a fan summary and the fault chips;
  • tiny: a power bar, the hottest temperatures and the faults, one line each.
• Header. The machine (FRU product), the BMC vendor and firmware (iLO fw 2.82, ASUS fw 1.02) and the BMC's LAN address ride the top border.
• Power. A braille semicircle gauge of the instantaneous draw (dcmi power reading) against the supplies' rated output (their sensors' upper thresholds), or the highest draw seen when the BMC does not state one, with a thin inner arc spanning the BMC's own min..max window and the average marked. Under it a history graph of the draw while there is room, then one bar per supply: input → output watts and efficiency where both are measured (an absent bay says absent), and the other power rails (CPU 112 W · Memory 8 W). A BMC without DCMI falls back to the supplies' summed input or a power-meter sensor.
• Temperatures. One gradient meter per sensor, filled from cool up to the sensor's OWN critical threshold (class defaults when it has none: intake 45 °C, DIMMs 85, CPUs 95, regulators 110, else 90), the limit printed after it; intake/ambient air is highlighted and listed first. When not every sensor fits, the hottest relative to its limit come first and the border says +N more. Wide entries add a braille sparkline of the sensor's last readings.
• Fans. A bar per fan, RPM against its upper threshold or the fastest fan seen, or percent duty (HP iLO); the section title carries the redundancy state (redundant, redundancy lost, …) when the BMC reports one.
• Voltages. A centred deviation bar per rail: the track spans its lower..upper non-critical thresholds, nominal (from the name, +12V, +3.3VSB, VBAT) sits on the centre tick, and the dot shows how far the reading has drifted.
• Status. Chips for chassis power, cooling/fan fault, drive fault, intrusion, the supplies present and any sensor alarms, then the SEL fill (full · 64 events turns red: most BMCs drop new events into a full log) and its newest entry. ipmi_show_serials adds the FRU serials (off by default, for screenshots).
• Colours. States follow the process gradient (ok / non-critical / critical = its start / middle / end: green, yellow, red in Default; mint, lemon, pink in pastel); meters use the theme's temp, download, available, free and cpu gradients. TTY mode draws no braille (the gauge becomes a bar, no history or sparklines) and only btop's console glyphs.
• Data. ipmitool -I open (in-band, /dev/ipmi0), run on the event loop, one child at a time, never blocking input. Once per session: mc info, fru print 0, lan print 1..8 (until a channel answers with an address) and sdr dump into a cache file candy-top creates itself (0600, in a 0700 per-user candy-top-<uid> directory under $XDG_RUNTIME_DIR or the temp dir; removed on exit, and a crashed run's leftovers are swept at the next start). Every data tick: dcmi power reading (~0.05 s). Every ipmi_update_ms (default 10 s): chassis status, sel info (+ sel elist last 1 when the log changed) and -S <cache> sdr elist for the values (~0.5 s with the cache; 8.8 s without). Thresholds come from one sensor list walk in the second round (4 s on HP iLO 4, 14-29 s on a loaded ASUS/AMI board — the reason values are not read that way). During that one walk no power reading lands, and the bottom border says reading thresholds…. Every BMC string is sanitised before display (escape sequences, C1 controls, invalid UTF-8), each ipmitool's output is capped at 4 MiB, and no new ipmitool starts while a killed one is still stuck in the driver. The box is sampled only while shown.
• Unavailable. No ipmitool, no device node, or no access (it is root-only: "BMC needs root (/dev/ipmi0)") shows that one-line reason and stops polling, retrying after 60 s and then less and less often. A BMC that refuses (BMC not responding) or hangs past the command's timeout (killed; BMC timed out) backs off the same way, from 15 s; the last readings stay on screen with the reason on the bottom border.
• FreeBSD. ipmitool works the same way through ipmi(4)'s /dev/ipmi0.

gpu boxes

Up to six gpu boxes can be shown at once (btop #1730), one per accelerator: gpu0, gpu1, ... in shown_boxes, numbered GPUs first and then NPUs. Data, collectors and caveats are in GPU.

• Slots and keys. The number keys 5, 6, 7, 8, 9 and 0 toggle gpu box slots 0 to 5, and each box's title shows its slot key (none for 0). Opening a slot shows the first accelerator, from the slot's index on, that has no box yet. A toggle that would not fit the terminal opens the size-error box instead. Slots are runtime state: they are never saved, and changing shown_boxes any other way (options menu, preset, reload) resets them.
• Retargeting. While more than one accelerator exists and the box is wide enough, the title carries a ← gpuN → selector. Clicking an arrow moves that box to the previous or next accelerator that has no box, keeping its slot. A move that would not fit is ignored.
• Grid (btop #1881). Gpu boxes are placed side by side, all one width and height, with one blank column between them. gpu_box_columns is Auto (as many per row as the terminal fits, a box being at least 34 columns wide) or a number from 1 to 6 to force the columns, still capped by what fits.
• Detail levels (btop #1881). The box width picks how much is drawn. Full (56 columns or more) shows everything, Compact (44 or more) drops the encoder/decoder and memory sections, and Minimal also drops the power row.
• Contents. A utilisation graph (graph_symbol_gpu, mirrored with gpu_mirror_graph) and meter, temperature, power with P-state, clocks, encoder/decoder use and VRAM used/total with its own graph, each where the device reports it. The stats sub-box is titled with custom_gpu_nameN or the model name.
• NPUs (btop #985, #1839). An NPU box is titled npu, its meter reads NPU and its memory reads ram instead of vram.
• Startup and presets. At startup a gpuN beyond the detected accelerators resets shown_boxes to the default, as btop does. A preset naming an accelerator that does not exist is refused with the size-error box.

Menus and overlays

While a menu is open, the frame behind it is dimmed to inactive_fg. With background_update = false, and always in TTY mode, that dimmed frame is also frozen. Menus re-centre when the terminal is resized. The main, help, options and signal-chooser menus need at least 80x24, and the other menus need 50x20. On a smaller terminal a size-error box is shown instead.

• Main menu (Esc, m, or the m menu button in the cpu border). Shows the banner and three block-letter entries: Options, Help and Quit. Use the arrows, Tab or j/k to move and Enter or Space to open. Options and Help open on top of the main menu, which comes back when they close.
• Options menu (F2, o). A 78-column box with tabs 0 general, 1 cpu, 2 mem, 3 net, 4 proc and 5 gpu (btop #1411). The gpu tab appears only once a GPU has answered. Options are grouped under non-selectable headings (btop #1791b), and the selected option's description is shown on the right.
  • Up and down move between options, skipping headings. Page Up and Page Down flip pages.
  • Tab and Shift+Tab change tabs, and a digit picks a tab directly.
  • ← and → flip a boolean, step a number (update_ms by 100), or cycle a list. color_theme cycles the installed themes. cpu_graph_*, cpu_sensor and selected_battery cycle what the collectors reported.
  • Enter, e or E edits a number or a text value inline. Enter applies the edit and Esc cancels it.
  • Every change applies live: the layout, colours, graph symbols and theme change at once. A theme change also re-paints the dimmed frame, so you can preview themes. A value btop would reject opens a warning box inside the menu instead of being applied.
  • Esc, q, o, Backspace or a click outside the box closes the menu.
• Help (F1, ?, h, or H with vim_keys). Lists every key in the key table, paged when the terminal is short.
• Signal chooser (s). A 5-column grid of signals 1 to 31 (16, SIGSTKFLT, is skipped). Type a number, move with the arrows or h/j/k/l, and press Enter or Space to send.
• Renice (N). A nice value from -20 to 19. Type a value, step with up and down (by 1) or left and right (by 5), and press Enter to apply.
• Message boxes. These are the terminate and kill confirmations (Yes/No), the signal and renice failure box, the "terminal too small" box for a toggle or preset that would not fit, and warning boxes for an invalid option value, a config-save failure, or a load warning on ctrl+r reload.

Presets

p cycles forward through the layout presets and Shift+p cycles backward. Preset 0 is always every box with default settings. The presets option defines up to 9 more, separated by whitespace. Each preset is a comma-separated list of boxes:

box:P:G          P = 0|1 alternate position, G = graph symbol (default|braille|block|block2|tty)
proc:P:G:W       proc only: W = proc box width percent (0-100) or "default" (btop PR #1476)

The default is cpu:1:default,proc:0:default cpu:0:default,mem:0:default,net:0:default cpu:0:block,net:0:tty.

• The alternate position maps to cpu_bottom, mem_below_net and proc_left.
• A ctr entry (btop #1873) shows the containers box. Its position and graph symbol are ignored; the box draws with graph_symbol_proc.
• A proc entry always sets proc_box_width_percent, to its W value or to 55 when W is missing.
• W is written back only when you wrote it. Stock btop 1.4.7 rejects a whole presets string that contains a W field and falls back to its default.
• disable_presets turns off the default preset (Default), the custom presets (Custom) or all of them (All).
• A preset that would not fit the terminal opens the size-error box and keeps the current preset.
• Toggling a box, changing shown_boxes, presets or the proc width, or setting disable_presets to anything other than Off drops the preset index.

The p button in the cpu border cycles presets too.

Proc box width (btop PR #1476). When mem or net is shown alongside proc:

• Shift+← / Shift+→ change proc_box_width_percent by 1%.
• Alt+Shift+← / Alt+Shift+→ change it by 10%.
• Ctrl+Shift+← / Ctrl+Shift+→ jump to the widest or narrowest width (mirrored with proc_left).
• Ctrl+Shift+↓ resets it to 55.

The width is clamped to the narrowest and widest layout the window allows.

Key bindings

The table below is generated from SugarCraft\Top\Input\KeyTable, the same roster the help overlay and --help print. tests/Docs/ReadmeKeyTableDriftTest.php fails when the two disagree, and tests/Input/KeyTableTest.php checks each documented key against the real handlers.

Context rules, following btop's input handling:

• ctrl+c always quits.
• An open menu takes every key first.
• An active process filter takes every key, including q.
• The proc box claims +, -, =, Space and C only while the tree view is on and a row is selected. Otherwise +, - and = step update_ms. Holding + or - accelerates to 1000 ms steps; = steps like + but never accelerates.
• j, k, g, G, h and l move only with vim_keys. Plain k is kill and plain h is help, so with vim_keys on, those become K and H.
• A modified arrow btop has no name for (for example Shift+↑ or Alt+←) is ignored.

Key	Action	btop key names
Mouse 1	Clicks buttons and selects in process list.	mouse_click, mouse_drag, mouse_release
Mouse scroll	Scrolls any scrollable list/text under cursor.	mouse_scroll_up, mouse_scroll_down
Esc, m	Toggles main menu.	escape, m
p	Cycle view presets forwards.	p
shift + p	Cycle view presets backwards.	P
1	Toggle CPU box.	1
2	Toggle MEM box.	2
3	Toggle NET box.	3
4	Toggle PROC box.	4
5, 6, 7, 8, 9, 0	Toggle GPU box.	5, 6, 7, 8, 9, 0
x	Toggle CTR (containers) box.	x
[, ]	Select previous/next container in CTR box.	[, ]
v	Toggle the VM dashboard (hides mem, net, proc, ctr).	v
s, S	Next/previous VM card order (VM dashboard).	s, S
shift + i	Toggle the ipmi box (BMC power, fans, temps; root).	I
d	Toggle disks view in MEM box.	d
F2, o	Shows options.	f2, o
F1, ?, h	Shows this window.	f1, ?, h
ctrl + r	Reloads config file from disk.	ctrl+r
q, ctrl + c	Quits program.	q, ctrl+c
+, -, =	Add/Subtract 100ms to/from update timer.	+, -, =
Up, Down	Select in process list.	up, down
Enter	Show detailed information for selected process.	enter
Spacebar	Expand/collapse the selected process in tree view.	space
C	Expand/collapse the selected process' children.	C
Pg Up, Pg Down	Jump 1 page in process list.	page_up, page_down
Home, End	Jump to first or last page in process list.	home, end
Left, Right	Select previous/next sorting column.	left, right
b, n	Select previous/next network device.	b, n
i	Toggle disks io mode with big graphs.	i
z	Toggle totals reset for current network device	z
a	Toggle auto scaling for the network graphs.	a
y	Toggle synced scaling mode for network graphs.	y
f, /	To enter a process filter. Start with ! for regex.	f, /
F	Follow selected process.	F
u	Pause process list.	u
delete	Clear any entered filter.	delete
c	Toggle per-core cpu usage of processes.	c
r	Reverse sorting order in processes box.	r
e	Toggle processes tree view.	e
E	Collapse/expand all processes in tree view.	E
%	Toggles memory display mode in processes box.	%
O	Toggle hiding containers and VMs in process list.	O
g, ctrl + g	Toggle GPU-only process filter (vim_keys: ctrl + g).	g, ctrl+g
Selected +, -	Expand/collapse the selected process in tree view.	+, -, =
Selected t	Terminate selected process with SIGTERM - 15.	t
Selected k (vim K)	Kill selected process with SIGKILL - 9.	k
Selected s	Select or enter signal to send to process.	s
Selected N	Select new nice value for selected process.	N
Shift + Left, Right	Adjust the proc box width by 1% (mem or net shown).	shift_left, shift_right
Alt+Shift+Left/Right	Adjust the proc box width by 10% (mem or net shown).	alt_shift_left, alt_shift_right
Ctrl+Shift+Left	Proc box to max width (min with proc_left).	ctrl_shift_left
Ctrl+Shift+Right	Proc box to min width (max with proc_left).	ctrl_shift_right
Ctrl+Shift+Down	Reset the proc box width percentage to 55%.	ctrl_shift_down
h, j, k, l	With vim_keys: left, down, up, right in lists.	h, j, k, l
g, G	With vim_keys: first / last process in the list.	g, G
H, K	With vim_keys: help and kill (h and k move).	H, K

Mouse

Mouse reporting is on unless disable_mouse is set. The mode is button and motion tracking (?1002h + SGR ?1006h), the same as btop, and flipping the option at runtime turns reporting on or off at once.

Where	Action
cpu border: the m menu button, the p preset button, the x ctr button, the vms button, the IPMI button, - / + around the interval	Opens the main menu, cycles the preset, toggles the containers box, toggles the VM dashboard, toggles the ipmi box, steps update_ms (the same as the keys, hold acceleration included).
VM dashboard: cards, sort ‹ cpu ›	A click selects a card, and a click on the selected card opens it in the proc box (as Enter). The button halves cycle the order back / forward. The wheel moves the selection a row, or scrolls when nothing is selected.
mem border: disks, io	Toggle show_disks / io_mode.
net border: the b/n, z, a and y buttons	Previous or next interface, zero the totals, auto-scale, sync. The a and y buttons appear only when the box is wide enough.
proc border buttons	filter, clear filter, O containers, per-core, reverse, tree, ← / → sorting, pause, info (detail), and with a selection terminate, kill, signals, Nice, Follow.
ctr border: [ select ]; ctr rows	The left and right halves of the button select the previous / next container. Clicking a row selects it, and clicking the selected row clears the selection.
proc list	Click selects. Clicking the selected row opens the detail view, and clicking a [-]/[+] marker toggles a branch. The wheel scrolls by 3. The scrollbar pages at its arrows, the thumb can be dragged, and a click on the track jumps proportionally.
any other left click	Clears the process selection, as btop does.
menus	Click entries, tabs, ←/→ arrows and buttons. The wheel moves selections and pages. A click outside a menu closes it.

Only bare left presses act as clicks. Right and middle clicks and modified clicks are dropped, as in btop.

Configuration

Location. The config is read from $XDG_CONFIG_HOME/candy-top/config.conf, or ~/.config/candy-top/config.conf when XDG_CONFIG_HOME is unset or not absolute. --config <path> reads another file and makes that file the save target. The directory is named candy-top so btop's own file is never touched.

Format. The format is btop's own: # comments and name = value lines, with strings in double quotes. A btop btop.conf copied over loads as-is. Unknown keys are skipped silently, so files from other btop versions also load. A value that fails validation is dropped with a warning on stderr, and the option keeps its previous value. A later duplicate of a key wins.

Persistence (btop's write_new and clean_quit):

• The file is rewritten on exit when save_config_on_exit is on and something persisted changed. That includes options changed in the menu or by keys, box toggles and presets. A file that was missing, outdated or held invalid values is rewritten too.
• The save runs on every quit path: q, ctrl+c, the main menu's Quit, SIGTERM and SIGHUP (via ext-pcntl), and even after a crash, once the terminal has been restored.
• Turning save_config_on_exit off in the options menu writes the file at once, so the choice itself is saved.
• Writes are atomic: a temp file is written in the same directory, fsynced, then renamed into place. A symlinked config is followed and its target replaced, so the link survives. An existing file's permission bits are kept. A read-only file is never replaced; the failure is reported instead. A directory candy-top creates gets mode 0700.
• If a save fails mid-session, a warning box opens. If it fails on exit, the error is printed on stderr and candy-top exits with status 1.

Tree state (btop #1791c). With proc_tree_persist_state on, the branches you collapse or expand in the tree view (space, +/-/=, C, or a click on the [+]/[-] marker) are remembered across runs. They are stored in $XDG_STATE_HOME/candy-top/tree-state.json, or ~/.local/state/candy-top/tree-state.json when XDG_STATE_HOME is unset or not absolute. They are not stored in config.conf, unlike in the btop PR, so the config stays btop-compatible and is not rewritten on every collapse. PIDs change between runs, so a choice is keyed by the chain of process names from the tree root (for example systemd → sshd → bash), and processes with the same chain share a choice. A remembered choice is applied when a process first appears, and it overrides proc_tree_auto_collapse. E (all branches) is not remembered. The file is written atomically about two seconds after a change, and on exit (including SIGTERM/SIGHUP and crash exits) when anything is still unsaved. Nothing is written while the option is off; turning it off drops a pending write. It keeps at most 512 chains, drops the least recently used first, and forgets a chain unused for 90 days. A missing, unreadable or corrupt file is ignored. A failed write is reported on stderr at exit and never changes the exit status.

Reload. ctrl+r reloads the file over the running config. Runtime state such as the filter, the selection and the detailed view is kept, the theme list is rescanned and the theme is reloaded. The first load warning, if any, is shown in a warning box. A reload is not counted as a change that needs saving.

Config keys

These are all persisted keys, in config.conf write order, generated from SugarCraft\Top\Config\Schema and the options-menu catalog. tests/Docs/ReadmeConfigTableDriftTest.php fails when they disagree. "Options menu" gives the tab number, the tab and the section heading where the key is edited. Descriptions are the comment lines written into config.conf. Runtime-only state (tty_mode, proc_filter, show_detailed, pause_proc_list, ...) is never written and is not listed.

Key	Type	Default	Allowed values	Options menu	Description
color_theme	string	"pastel"	any text	0 general › Appearance	Name of a btop++/bpytop/bashtop formatted ".theme" file, "Default" and "TTY" for builtin themes. candy-top's default is the bundled "pastel" theme (btop's is "Default"). Themes should be placed in "$XDG_CONFIG_HOME/candy-top/themes" or the candy-top themes directory.
theme_background	bool	true	true, false	0 general › Appearance	If the theme set background should be shown, set to False if you want terminal background transparency.
truecolor	bool	true	true, false	0 general › Appearance	Sets if 24-bit truecolor should be used, will convert 24-bit colors to 256 color (6x6x6 color cube) if false.
force_tty	bool	false	true, false	0 general › Terminal and input	Set to true to force tty mode regardless if a real tty has been detected or not. Will force 16-color mode and TTY theme, set all graph symbols to "tty" and swap out other non tty friendly symbols.
disable_presets	string	"Off"	Off, Default, Custom, All	0 general › Layout	Option to disable presets. Either the default preset, custom presets, or all presets. "Off" All presets are enabled. "Default" preset is disabled. "Custom" presets are disabled. "All" presets are disabled.
presets	string	"cpu:1:default,proc:0:default cpu:0:default,mem:0:default,net:0:default cpu:0:block,net:0:tty"	validated text (see description)	0 general › Layout	Define presets for the layout of the boxes. Preset 0 is always all boxes shown with default settings. Max 9 presets. Format: "box_name:P:G,box_name:P:G" P=(0 or 1) for alternate positions, G=graph symbol to use for box. proc box format can also be "proc:P:G:W" W=(0-100 or default) for proc width percentage. Stock btop 1.4.7 rejects a presets value holding a W field and resets presets to its default. Use whitespace " " as separator between different presets. Example: "cpu:0:default,mem:0:tty,proc:1:default cpu:0:braille,proc:0:tty"
vim_keys	bool	false	true, false	0 general › Terminal and input	Set to True to enable "h,j,k,l,g,G" keys for directional control in lists. Conflicting keys for h:"help" and k:"kill" is accessible while holding shift.
disable_mouse	bool	false	true, false	0 general › Terminal and input	Disable all mouse events.
rounded_corners	bool	true	true, false	0 general › Runtime and rendering	Rounded corners on boxes, is ignored if TTY mode is ON.
terminal_sync	bool	true	true, false	0 general › Runtime and rendering	Accepted for btop.conf compatibility, not used yet. Use terminal synchronized output sequences to reduce flickering on supported terminals.
graph_symbol	string	"braille"	braille, block, block2, tty	0 general › Graph glyphs	Default symbols to use for graph creation, "braille", "block", "block2" or "tty". "braille" offers the highest resolution but might not be included in all fonts. "block" has half the resolution of braille but uses more common characters. "block2"'s resolution is between braille and block, but it has a cleaner look than braille (needs a font with Unicode 13 sextants). "tty" uses only 3 different symbols but will work with most fonts and should work in a real TTY. Note that "tty" only has half the horizontal resolution of the other two, so will show a shorter historical view. Stock btop 1.4.7 does not know "block2" and falls back to its default with a warning.
graph_symbol_cpu	string	"default"	default, braille, block, block2, tty	0 general › Graph glyphs	Graph symbol to use for graphs in cpu box, "default", "braille", "block", "block2" or "tty".
graph_symbol_gpu	string	"default"	default, braille, block, block2, tty	0 general › Graph glyphs	Graph symbol to use for graphs in gpu box, "default", "braille", "block", "block2" or "tty".
graph_symbol_mem	string	"default"	default, braille, block, block2, tty	0 general › Graph glyphs	Graph symbol to use for graphs in mem box, "default", "braille", "block", "block2" or "tty".
graph_symbol_net	string	"default"	default, braille, block, block2, tty	0 general › Graph glyphs	Graph symbol to use for graphs in net box, "default", "braille", "block", "block2" or "tty".
graph_symbol_proc	string	"default"	default, braille, block, block2, tty	0 general › Graph glyphs	Graph symbol to use for graphs in proc box, "default", "braille", "block", "block2" or "tty".
shown_boxes	string	"cpu mem net proc"	validated text (see description)	0 general › Layout	Manually set which boxes to show. Available values are "cpu mem net proc ctr vms ipmi" and "gpuN" for GPU index N, separate values with whitespace. "vms" (the VM dashboard) hides mem, net, proc and ctr while shown; "ipmi" (the BMC box) is a band under the cpu box. Up to 6 GPU boxes can be shown at once.
update_ms	int	2000	100–86400000	0 general › Runtime and rendering	Update time in milliseconds, recommended 2000 ms or above for better sample times for graphs.
proc_sorting	string	"cpu lazy"	pid, name, command, threads, user, memory, cpu direct, cpu lazy, io read, io write, io total, gpu, gpu memory	4 proc › Order and tree	Processes sorting, "pid" "name" "command" "threads" "user" "memory" "cpu lazy" "cpu direct" "io read" "io write" "io total" "gpu" "gpu memory", "cpu lazy" sorts top process over time (easier to follow), "cpu direct" updates top process directly. "io read", "io write" and "io total" sort by disk IO rate, "gpu" and "gpu memory" by per-process GPU use; stock btop 1.4.7 does not know them and falls back to "cpu lazy" with a warning.
proc_reversed	bool	false	true, false	4 proc › Order and tree	Reverse sorting order, True or False.
proc_tree	bool	false	true, false	4 proc › Order and tree	Show processes as a tree.
proc_command_basename	bool	false	true, false	4 proc › Rows and selection	Show only the executable basename in process commands, preserving arguments. The detailed view still shows the full command.
proc_tree_persist_state	bool	false	true, false	4 proc › Order and tree	Persist manual tree expand/collapse choices by process-name ancestry across runs. Stored in $XDG_STATE_HOME/candy-top/tree-state.json, not in this file.
proc_colors	bool	true	true, false	4 proc › Rows and selection	Use the cpu graph colors in the process list.
proc_gradient	bool	true	true, false	4 proc › Rows and selection	Use a darkening gradient in the process list.
proc_per_core	bool	false	true, false	4 proc › Rows and selection	If process cpu usage should be of the core it's running on or usage of the total available cpu power.
proc_mem_bytes	bool	true	true, false	4 proc › Rows and selection	Show process memory as bytes instead of percent.
proc_cpu_graphs	bool	true	true, false	4 proc › Rows and selection	Show cpu graph for each process.
proc_gpu_graphs	bool	true	true, false	4 proc › Rows and selection	Show gpu graph for each process.
proc_gpu_only	bool	false	true, false	4 proc › Rows and selection	Show only processes with active GPU usage or GPU memory allocation in the process list.
proc_info_smaps	bool	false	true, false	4 proc › Rows and selection	Accepted for btop.conf compatibility, not used yet. Use /proc/[pid]/smaps for memory information in the process info box (very slow but more accurate)
proc_box_width_percent	int	55	0–100	0 general › Layout	Percentage value for proc box width when mem or net is shown. Values 0-100; the width is clamped to the narrowest/widest layout the window allows.
proc_left	bool	false	true, false	0 general › Layout	Show proc box on left side of screen instead of right.
proc_filter_kernel	bool	false	true, false	4 proc › Rows and selection	(Linux) Filter processes tied to the Linux kernel(similar behavior to htop).
proc_filter_containers	bool	false	true, false	4 proc › Rows and selection	(Linux) Hide processes running in containers (docker, podman, kubernetes, lxc, systemd-nspawn...) from the process list.
ctr_show_vms	bool	true	true, false	4 proc › Rows and selection	(Linux) Show libvirt/KVM virtual machines in the containers box, beside the containers.
vms_sorting	string	"cpu"	cpu, mem, disk, net, psi, name	4 proc › Rows and selection	VM dashboard card order. Possible values: "cpu", "mem", "disk", "net", "psi" and "name". The first five put the busiest guest first; "psi" is the worst cpu/memory/io pressure.
ipmi_update_ms	int	10000	1000–86400000	4 proc › Rows and selection	Milliseconds between the ipmi box's slow BMC reads (sensor values, chassis status, event log); the power reading follows update_ms. Min 1000.
ipmi_show_serials	bool	false	true, false	4 proc › Rows and selection	Show the FRU serial numbers (chassis, board, product) in the ipmi box. Off by default so screenshots stay clean.
proc_follow_detailed	bool	true	true, false	4 proc › Rows and selection	Should the process list follow the selected process when detailed view is open.
proc_aggregate	bool	false	true, false	4 proc › Order and tree	In tree-view, always accumulate child process resources in the parent process.
proc_tree_auto_collapse	int	0	0–10000	4 proc › Order and tree	In tree-view, auto-collapse processes with this many or more direct children when entering tree mode. 0 to disable. Useful for collapsing multi-process apps like browsers.
keep_dead_proc_usage	bool	false	true, false	4 proc › Rows and selection	Accepted for btop.conf compatibility, not used yet. Should cpu and memory usage display be preserved for dead processes when paused.
cpu_graph_upper	string	"Auto"	any text	1 cpu › Graphs	Sets the CPU stat shown in upper half of the CPU graph, "total" is always available. Select from a list of detected attributes from the options menu.
cpu_graph_lower	string	"Auto"	any text	1 cpu › Graphs	Sets the CPU stat shown in lower half of the CPU graph, "total" is always available. Select from a list of detected attributes from the options menu.
show_gpu_info	string	"Auto"	Auto, On, Off	1 cpu › Graphs	If gpu info should be shown in the cpu box. Available values = "Auto", "On" and "Off".
gpu_box_columns	string	"Auto"	validated text (see description)	5 gpu › Display	How many gpu boxes to place side by side instead of stacking them vertically. "Auto" uses as many columns as the terminal width allows, or set a number (1-6) to force it.
cpu_invert_lower	bool	true	true, false	1 cpu › Graphs	Toggles if the lower CPU graph should be inverted.
cpu_single_graph	bool	false	true, false	1 cpu › Graphs	Set to True to completely disable the lower CPU graph.
cpu_bottom	bool	false	true, false	0 general › Layout	Show cpu box at bottom of screen instead of top.
show_uptime	bool	true	true, false	1 cpu › CPU status	Shows the system uptime in the CPU box.
show_cpu_watts	bool	true	true, false	1 cpu › CPU status	Accepted for btop.conf compatibility, not used yet. Shows the CPU package current power consumption in watts. Requires read access to the RAPL energy counters.
check_temp	bool	true	true, false	1 cpu › Temperature sensors	Show cpu temperature.
cpu_sensor	string	"Auto"	any text	1 cpu › Temperature sensors	Restart needed. Which sensor to use for cpu temperature, use options menu to select from list of available sensors.
show_coretemp	bool	true	true, false	1 cpu › Temperature sensors	Show temperatures for cpu cores also if check_temp is True and sensors has been found.
cpu_core_map	string	""	validated text (see description)	1 cpu › Temperature sensors	Set a custom mapping between core and coretemp, can be needed on certain cpus to get correct temperature for correct core. Use lm-sensors or similar to see which cores are reporting temperatures on your machine. Format "x:y" x=core with wrong temp, y=core with correct temp, use space as separator between multiple entries. Example: "4:0 5:1 6:3"
temp_scale	string	"celsius"	celsius, fahrenheit, kelvin, rankine	1 cpu › Temperature sensors	Which temperature scale to use, available values: "celsius", "fahrenheit", "kelvin" and "rankine".
base_10_sizes	bool	false	true, false	0 general › Status and units	Use base 10 for bits/bytes sizes, KB = 1000 instead of KiB = 1024.
show_cpu_freq	bool	true	true, false	1 cpu › CPU status	Show CPU frequency.
freq_mode	string	"first"	first, range, lowest, highest, average	1 cpu › CPU status	Restart needed. How to calculate CPU frequency, available values: "first", "range", "lowest", "highest" and "average".
show_core_freq	string	"off"	off, value, graph	1 cpu › CPU status	Show per-core CPU frequency, available values: "off", "value", "graph".
clock_format	string	"%X"	any text	0 general › Status and units	Draw a clock at top of screen, formatting according to strftime, empty string to disable. Special formatting: /host = hostname | /user = username | /uptime = system uptime
background_update	bool	true	true, false	0 general › Status and units	Update main ui in background when menus are showing, set this to false if the menus is flickering too much for comfort.
custom_cpu_name	string	""	any text	1 cpu › CPU status	Custom cpu model name, empty string to disable.
disks_filter	string	""	any text	2 mem › Disk selection	Optional filter for shown disks, should be full path of a mountpoint, separate multiple values with whitespace " ". Only disks matching the filter will be shown. Prepend exclude= to only show disks not matching the filter. Examples: disks_filter="/boot /home/user", disks_filter="exclude=/boot /home/user"
disks_order	string	""	any text	2 mem › Disk selection	Optional custom display order for disks, full mountpoint paths separated by whitespace " ". Use "swap" to position the swap entry. Listed disks are shown first in the given order, any remaining disks follow in their default order. Example: disks_order="/ swap /home"
mem_graphs	bool	true	true, false	2 mem › Memory and swap	Show graphs instead of meters for memory values.
mem_selected	string	"default"	default, used, available, cached, free, swap_used	2 mem › Memory and swap	Focuses only one kind of memory metric, available values: "default", "used", "available", "cached", "free", or "swap_used".
mem_below_net	bool	false	true, false	0 general › Layout	Show mem box below net box instead of above.
zfs_arc_cached	bool	true	true, false	2 mem › Disk selection	Restart needed. Count ZFS ARC in cached and available memory.
show_swap	bool	true	true, false	2 mem › I/O graphs	If swap memory should be shown in memory box.
show_zswap	bool	true	true, false	2 mem › I/O graphs	(Linux) If zswap usage should be shown in memory box.
swap_disk	bool	true	true, false	2 mem › I/O graphs	Show swap as a disk, ignores show_swap value above, inserts itself after first disk.
show_disks	bool	true	true, false	2 mem › Memory and swap	If mem box should be split to also show disks info.
only_physical	bool	true	true, false	2 mem › Disk selection	Filter out non physical disks. Set this to False to include network disks, RAM disks and similar.
use_fstab	bool	true	true, false	2 mem › Disk selection	Read disks list from /etc/fstab. This also disables only_physical.
zfs_hide_datasets	bool	false	true, false	2 mem › Disk selection	Setting this to True will hide all datasets, and only show ZFS pools. (IO stats will be calculated per-pool)
disk_free_priv	bool	false	true, false	2 mem › Disk selection	Accepted for btop.conf compatibility, not used yet. Set to true to show available disk space for privileged users.
show_io_stat	bool	true	true, false	2 mem › I/O graphs	Toggles if io activity % (disk busy time) should be shown in regular disk usage view.
io_mode	bool	false	true, false	2 mem › I/O graphs	Toggles io mode for disks, showing big graphs for disk read/write speeds.
io_graph_combined	bool	false	true, false	2 mem › I/O graphs	Set to True to show combined read/write io graphs in io mode.
io_graph_speeds	string	""	validated text (see description)	2 mem › I/O graphs	Set the top speed for the io graphs in MiB/s (100 by default), use format "mountpoint:speed" separate disks with whitespace " ". Example: "/mnt/media:100 /:20 /boot:1".
swap_upload_download	bool	false	true, false	3 net › Graphs and scale	Swap the positions of the upload and download speed graphs. When true, upload will be on top.
net_download	int	100	0–2147483647	3 net › Graphs and scale	Set fixed values for network graphs in Mebibits. Is only used if net_auto is also set to False.
net_upload	int	100	0–2147483647	3 net › Graphs and scale	—
net_auto	bool	true	true, false	3 net › Graphs and scale	Use network graphs auto rescaling mode, ignores any values set above and rescales down to 10 Kibibytes at the lowest.
net_sync	bool	true	true, false	3 net › Graphs and scale	Sync the auto scaling for download and upload to whichever currently has the highest scale.
net_iface	string	""	any text	3 net › Interface and units	Starts with the Network Interface specified here.
base_10_bitrate	string	"Auto"	Auto, True, False	3 net › Interface and units	"True" shows bitrates in base 10 (Kbps, Mbps). "False" shows bitrates in binary sizes (Kibps, Mibps, etc.). "Auto" uses base_10_sizes.
net_hide_ip	bool	false	true, false	3 net › Interface and units	Toggles ip address visibility in the net box.
show_battery	bool	true	true, false	0 general › Status and units	Show battery stats in top right if battery is present.
selected_battery	string	"Auto"	any text	0 general › Status and units	Which battery to use if multiple are present. "Auto" for auto detection.
show_battery_watts	bool	true	true, false	0 general › Status and units	Show power stats of battery next to charge indicator.
log_level	string	"WARNING"	DISABLED, ERROR, WARNING, INFO, DEBUG	0 general › Diagnostics and persistence	Accepted for btop.conf compatibility, not used yet. Set loglevel for "~/.local/state/candy-top.log" levels are: "ERROR" "WARNING" "INFO" "DEBUG". The level set includes all lower levels, i.e. "DEBUG" will show all logging info.
save_config_on_exit	bool	true	true, false	0 general › Diagnostics and persistence	Automatically save current settings to config file on exit.
nvml_measure_pcie_speeds	bool	true	true, false	5 gpu › Telemetry	Accepted for btop.conf compatibility, not used yet. Measure PCIe throughput on NVIDIA cards, may impact performance on certain cards.
rsmi_measure_pcie_speeds	bool	true	true, false	5 gpu › Telemetry	Accepted for btop.conf compatibility, not used yet. Measure PCIe throughput on AMD cards, may impact performance on certain cards.
gpu_mirror_graph	bool	true	true, false	5 gpu › Display	Horizontally mirror the GPU graph.
shown_gpus	string	"nvidia amd intel apple"	any text	5 gpu › Display	Set which GPU vendors to show. Available values are "nvidia amd intel apple"
custom_gpu_name0	string	""	any text	5 gpu › Names	Custom gpu0 model name, empty string to disable.
custom_gpu_name1	string	""	any text	5 gpu › Names	Custom gpu1 model name, empty string to disable.
custom_gpu_name2	string	""	any text	5 gpu › Names	Custom gpu2 model name, empty string to disable.
custom_gpu_name3	string	""	any text	5 gpu › Names	Custom gpu3 model name, empty string to disable.
custom_gpu_name4	string	""	any text	5 gpu › Names	Custom gpu4 model name, empty string to disable.
custom_gpu_name5	string	""	any text	5 gpu › Names	Custom gpu5 model name, empty string to disable.

Themes

The default theme is pastel, candy-top's own: bright candy-shop pastels (bubblegum pink, lavender, electric mint, glowing peach, sky blue and lemon) on a deep plum-ink background. Load and temperature run mint → lemon → pink, the cpu graph sky → lavender → pink, and each box outline flows from one pastel into the next.

This is a deliberate deviation from btop, whose default is its builtin Default theme. Default is still in the list, and a btop config that sets color_theme (for example btop's own color_theme = "Default") keeps its theme. pastel paints its own background, so it looks the same on dark and light terminals. With theme_background = false it uses the terminal's background instead, which suits dark terminals only: on a light one the near-white text is unreadable, so choose a light theme there (flexoki-light, paper, solarized_light, ...). Without truecolor its colours are mapped to the nearest 256-colour entries and the outlines are drawn flat. A side-by-side of Default, mellow and pastel is in .assets/theme-compare.png.

color_theme names a btop/bpytop/bashtop .theme file, or one of the builtins Default and TTY. Themes are read from two directories:

1. The user directory, $XDG_CONFIG_HOME/candy-top/themes, or ~/.config/candy-top/themes.
2. The bundled candy-top/themes/ directory.

The list starts with Default and TTY, then every *.theme file from both directories in a single list sorted by file name. When both directories hold the same file name, both copies are listed, and the user copy comes first and wins every lookup by name.

To add a theme, drop any btop .theme file (theme[key]="#rrggbb" lines; "r g b" triplets and #gg greys also work) into the user directory, then pick it with ←/→ on color_theme in the options menu, or set color_theme = "name". A user file with the same name as a bundled one shadows the bundled theme; the bundled copy stays in the list and can still be selected there (it is then saved by full path). The theme list is scanned at startup and again on ctrl+r. An unknown or unreadable theme falls back to Default. theme_background = false drops the theme's background for a transparent terminal.

43 bundled theme files (candy-top/themes/) plus the builtin Default and TTY:

Default · TTY · HotPurpleTrafficLight · adapta · adwaita-dark · adwaita · ayu · dracula · dusklight · elementarish · everforest-dark-hard · everforest-dark-medium · everforest-light-medium · flat-remix-light · flat-remix · flexoki-dark · flexoki-light · gotham · greyscale · gruvbox_dark · gruvbox_dark_v2 · gruvbox_light · gruvbox_material_dark · horizon · kanagawa-dragon · kanagawa-lotus · kanagawa-wave · kyli0x · matcha-dark-sea · mellow · monokai · night-owl · nord · onedark · orange · paper · pastel · phoenix-night · solarized_dark · solarized_light · tokyo-night · tokyo-storm · tomorrow-night · twilight · whiteout

Box outline flows

candy-top reads four pairs of optional theme keys that btop does not have: cpu_box_mid/cpu_box_end, mem_box_mid/mem_box_end, net_box_mid/net_box_end and proc_box_mid/proc_box_end. When a box's _end key is set, its outline sweeps diagonally from <box>_box at the top-left corner, through _mid (optional) to _end at the bottom-right. Every line drawn in the box colour flows: the outline, title and button junctions, the clock and battery junctions, and the dividers inside the box. Inner sub-box lines drawn in div_line (the cpu info box, the mem/disks split, the net stats box, the proc detail view and the gpu stats box) get a quieter echo of the same flow. Titles, hotkeys and labels keep their own colours. The gpu boxes follow the cpu flow and the ctr box follows the proc flow, as they already use those box colours.

theme[cpu_box]="#bfa3ff"
theme[cpu_box_mid]="#ff9ad2"
theme[cpu_box_end]="#ffc49a"

Flows are drawn in truecolor only. With 256 colours, the 16-colour TTY theme or tty_mode, the outline uses the flat <box>_box colour. btop ignores these keys, so a theme that uses them still loads in btop with flat outlines. Themes that do not set them, which includes Default and every btop theme, look exactly as they do in btop.

The bundled themes are ported from btop (Apache-2.0; see themes/LICENSE and themes/README.md). mellow comes from btop PR #1683. pastel is original to candy-top. Theme colours are rendered byte-exact against btop's theme engine (see tests/Theme/BtopThemeOracleTest.php).

TTY mode

TTY mode is btop's mode for the Linux console and other limited terminals:

• It switches to the 16-colour TTY theme, whose gradients are stepped at 33/66 rather than interpolated.
• Every graph is forced to the tty symbol set and box corners are square.
• The dimmed frame behind menus is always frozen.

It turns on automatically when stdin is a real console, meaning posix_ttyname() starts with /dev/tty (/dev/tty1, a serial /dev/ttyS0, ...). Set force_tty = true to force it anywhere. There is no command-line flag; turning force_tty on in the options menu applies TTY mode at once, except on a real console, where it is always on.

Data sources and permissions

Collectors are chosen per OS at run time (SugarCraft\Top\Collect\Platform). They never fail: a value that cannot be read becomes "not measured" and is shown as blank or n/a, never as 0. A briefly failing reading keeps the last good value (btop #1008).

Linux

Box	Source
cpu	/proc/stat (per-core jiffies), /proc/loadavg, /proc/uptime; frequency from /sys/devices/system/cpu/cpufreq/policy*/scaling_cur_freq (per core from cpuN/cpufreq), falling back to /proc/cpuinfo; temperatures from /sys/class/hwmon (coretemp/k10temp-style temp*_input), falling back to /sys/class/thermal; battery from /sys/class/power_supply
mem	/proc/meminfo (zswap: Zswap/Zswapped), ZFS ARC from /proc/spl/kstat/zfs/arcstats
disks	/proc/mounts + statvfs, /proc/diskstats, /sys/block (physical filter), /etc/fstab (cached by mtime)
net	/proc/net/dev, /sys/class/net/<if>/{carrier,operstate}, addresses via net_get_interfaces()
proc	/proc/[pid]/{stat,status,cmdline,cgroup,io}, with cwd read for the detailed pid only
ctr	the proc scan's cgroup tags; /sys/fs/cgroup/<container>/{cpu.stat,memory.current,memory.stat,memory.max}; the docker socket for names
vms	/sys/fs/cgroup/machine.slice/machine-qemu*.scope/{cpu.stat,memory.current,memory.stat,io.stat,cpu.pressure,memory.pressure,io.pressure,libvirt/cgroup.procs}; /run/libvirt/qemu/*.xml (root); /proc/<qemu pid>/{io,cmdline}; /sys/class/net/<tap>/{address,statistics/rx_bytes,statistics/tx_bytes}; /proc/meminfo
ipmi	ipmitool -I open (/dev/ipmi0, root): mc info, fru print 0, lan print N, sdr dump, dcmi power reading, chassis status, sel info, sel elist last 1, sdr elist (against the dumped cache), sensor list once for thresholds
gpu	nvidia-smi (NVIDIA); amdgpu, i915/xe, intel_vpu and amdxdna nodes under /sys/class/drm and /sys/class/accel; per-process GPU use from nvidia-smi and /proc/[pid]/fdinfo (see GPU)

Permissions:

• Everything works unprivileged.
• /proc/[pid]/io and cwd of other users' processes need root or CAP_SYS_PTRACE. Without it, the IO columns show - and the cwd is empty. The same applies to /proc/[pid]/fdinfo, so without it the per-process GPU columns on AMD and Intel cover only your own processes.
• Signals and lowering nice values on other users' processes need the usual privileges. A refusal opens btop's error box.
• The ipmi box needs root (or read+write on /dev/ipmi0); without it the box says so and stops polling.

Per-process cmdline, status and cgroup are read once per process lifetime. Only stat is re-read each tick, plus io while the IO columns show (box at least 90 columns wide, 106 once per-process GPU data is measured) or an io * sort is active.

FreeBSD

On FreeBSD (PHP_OS = FreeBSD) a separate collector family reads the same figures through sysctl(8) and base-system tools: kern.cp_times, vm.loadavg, kern.boottime, vm.stats.*, swapinfo -k, netstat -i -b -n -W with ifconfig -a, iostat -x -I, mount -p with statvfs, ps, procstat -f (detail cwd), dev.cpu.N.{freq,temperature}, hw.acpi.thermal.* and hw.acpi.battery.*. Each tool runs as a short, time-bounded child with LC_ALL=C. The memory classes use the semantics of the four open FreeBSD upstream PRs (#1851, #1728, #1830, #1787): laundry counts as used, and cached is the buffer cache plus the reclaimable ARC.

The FreeBSD output parsing for ps, netstat -W, ifconfig and iostat has been checked against the man pages; captures from a live host are still pending.

Known limitations on FreeBSD:

• No per-process IO (FreeBSD exposes only block-op counts), so the IO columns show -.
• GPUs come from nvidia-smi only (no AMD, Intel or NPU readings).
• No zswap.
• No container or jail tags, so the containers box stays empty.
• One aggregate battery (acpi).
• With security.bsd.see_other_uids=0, an unprivileged user sees only their own processes.
• CPU interrupt time is counted as irq (busy) rather than dropped as btop's FreeBSD port does.
• ACPI thermal zones count as sensors even without coretemp.

Other systems

Any other OS uses the Linux collectors, which read "not measured" wherever /proc and /sys are missing. The UI runs, but most readings stay blank.

Containers and VMs

Each process's /proc/[pid]/cgroup is parsed (btop PR #1873). A process inside a container shows an [engine:name] tag at the start of its command column. The engines are docker, podman, k8s, containerd, lxc/Incus, systemd-nspawn, and others named by their OCI cgroup prefix. A nested container is attributed to the outermost one. The tag text is restricted to [A-Za-z0-9_.:-].

KVM/QEMU guests are tagged too, with engine kvm. This candy-top extension is not a btop feature. A guest is recognised from its libvirt/machined cgroup scope (machine-qemu\x2d<id>\x2d<name>.scope, qemu-<id>-<name>.libvirt-qemu) or from a QEMU command line (-name guest=..., -uuid, -smp, -m). It is never recognised by the executable name alone. The guest name is shown in the program column, and helpers that share the scope (swtpm, virtiofsd) carry the VM's tag.

O toggles proc_filter_containers, which hides containers and VMs alike. The text filter also matches the container or VM name.

The containers box groups the tagged processes per container and per libvirt guest and adds each one's own cgroup figures (ctr_show_vms turns the guests off). A machined scope is a VM exactly when it reads as qemu-<id>-<name> once its escapes are decoded, so an nspawn machine merely named like qemu (machine-qemubox.scope) is an nspawn container.

GPU

GPUs and NPUs are read by a multi-vendor collector (Collect\Gpu\Accelerators), a PHP re-implementation of btop's Gpu::collect without its NVML/ROCm/PMU libraries, which would need FFI. Several vendors at once are normal, such as an Intel iGPU next to an NVIDIA card. The backends present are picked on the first sample:

• NVIDIA: an nvidia-smi shell-out for utilisation, memory, temperature, power and power limit, clocks, P-state, fan and encoder/decoder use. Every candidate binary is tried before the GPU is given up as absent: each PATH hit, then the WSL2 location /usr/lib/wsl/lib/nvidia-smi and container-toolkit locations (btop #1869). A GPU-less host stops spawning after that. Queries are at least 5 s apart, run as background children whose output the event loop collects (the UI never waits for them), are killed after 2 s, and are backed off exponentially after a failure, so a wedged driver never freezes the UI.
• AMD (btop #1854): amdgpu sysfs nodes (busy percentages, VRAM, hwmon temperature, power, clocks, fan). Names come from amdgpu.ids, then pci.ids. A card in runtime suspend is not woken.
• Intel (btop #1888): every i915 and xe card, with utilisation from DRM fdinfo, clocks, and power and temperature on discrete cards. VRAM is not read, because neither driver exposes it in sysfs.
• NPUs: Intel NPUs through intel_vpu sysfs (btop #985: utilisation, memory in use, clock) and AMD Ryzen AI NPUs through amdxdna (btop #1839, detection only: the device is listed, every reading n/a).

On FreeBSD only the NVIDIA backend runs. shown_gpus filters the GPU vendors live (NPUs are never filtered), and custom_gpu_nameN renames a device in its gpu box.

GPUs are numbered 0..n-1 in backend order (NVIDIA, AMD, Intel) and NPUs number after them. A device keeps its index when its backend briefly drops it, so its graphs never jump to another device. One shared sampler feeds the gpu boxes, the cpu box's GPU sub-graphs and the proc box's GPU columns, so they all show the same snapshot and the host is sampled once per update however many of them are shown.

A device that stops answering keeps its last values (btop #1008), but only for a bounded time: once it has measured nothing for max(5, ceil(30 s / update_ms)) samples in a row, it is shown unmeasured (n/a) and its graph history is dropped, so a GPU that is gone for good does not show frozen numbers.

Cost. There is one GPU sampler, and it runs only while the cpu box (with GPU info), a gpu box or the proc box's GPU columns are shown and want GPUs (btop #1858). nvidia-smi queries at most once per 5 s, whatever the number of boxes. Per-process data is collected only while the proc box wants it (see proc), and stops within two updates after it no longer does. On NVIDIA that adds nvidia-smi --query-compute-apps and nvidia-smi pmon spawns. pmon takes about 0.25-1 s, but every nvidia-smi runs in the background: measured on a 4-GPU host, the UI used to stall about 0.7 s every query cycle; now the longest stall is the proc scan's 40-70 ms. The cpu box draws its CPU readings at once and its GPU rows when the query lands. The proc box joins the previous GPU sample instead of waiting, except right after g or a gpu sort, when it waits for fresh per-process values. The sysfs reads stay on the UI loop because they are cheap. On AMD and Intel the DRM fdinfo walk is spread across samples. Every nvidia-smi child is killed when candy-top exits. A child stuck in the driver ignores even SIGKILL, so after a short wait it is left to init.

Adopted upstream btop PRs

candy-top includes these open btop pull requests (evaluated 2026-10-08). New keys are additive, so a btop.conf loads in candy-top and a candy-top config.conf loads in stock btop. The exceptions are new values (block2, the io * sorts and the gpu / gpu memory sorts), which stock btop rejects with a warning before falling back to its default, and the presets W field described above.

PR	Feature
#1869	Try every nvidia-smi candidate (WSL2 path included) before memoising "no GPU".
#1730	GPU boxes for any GPU index: up to 6 gpuN boxes, slot keys 5-0, ← gpuN → title selectors, and the cpu box listing only GPUs without a box under show_gpu_info = Auto.
#1881	GPU box grid (gpu_box_columns) with Full, Compact and Minimal detail levels.
#985 / #1839	Intel and AMD NPUs, numbered after the GPUs in boxes titled npu. The AMD NPU is detected only, without readings.
#1854 / #1888	AMD GPUs from amdgpu sysfs (with amdgpu.ids names) and multiple Intel i915/xe GPUs.
#1552	Per-process Gpu% / GMem columns and mini GPU graph (proc_gpu_graphs), proc_gpu_only filter (g, ctrl+g), and gpu / gpu memory sorting.
#1856	Process names with spaces or parentheses parse correctly (regression fixtures).
#1739	zswap row and on-disk swap Used (show_zswap).
#1785 / #1792	Per-core CPU frequency (show_core_freq = off/value/graph) and the shared frequency label.
#1573	Interface IP address in the net box (net_hide_ip).
#1859	Executable basename in process commands (proc_command_basename).
#1823	Per-process IO/R and IO/W columns and io read/io write/io total sorting.
#1873	Container tags, proc_filter_containers (O), and the containers box (ctr: x, [/], row clicks, cgroup v2 figures, docker names).
#1783	block2 sextant graph symbols (graph_symbol*).
#1858	Hidden boxes are never sampled or drawn, and graph sizes are clamped to at least 1.
#1614	GPU sub-graph widths in the cpu box.
#1008	Keep the last value when a collector briefly fails (bounded for GPUs, see GPU).
#1747	mem_selected: a single focused mem graph.
#1700	disks_order.
#1546	Process cwd in the detailed view.
#1791	Tree siblings sorted by branch totals (a), grouped option headings (b), and (c) proc_tree_persist_state, stored in an XDG state file instead of config.conf.
#1476	proc_box_width_percent, Shift/Alt/Ctrl+Shift arrow width keys, and the presets W field.
#1411	Options tabs in box-toggle order (0-5) with digit selection.
#1849	Theme or config reload invalidates every cached render, including the battery meter.
#1683	The mellow theme.
#1851 / #1728 / #1830 / #1787	FreeBSD memory and battery fixes, in the FreeBSD collectors.

Differences from btop

These are deliberate deviations and gaps. Each phase's full notes are in CALIBER_LEARNINGS.md.

Not implemented (yet)

• No PCIe TX/RX line in the gpu boxes (nothing measures PCIe throughput), and no Apple GPUs.
• AMD NPUs are detected but not measured; Intel GPUs report no VRAM.
• No ctrl+z suspend.
• No CPU package watts (show_cpu_watts has no RAPL reader).
• No ZFS pool IO.
• No MAC-address fallback for an interface without an IP.
• Accepted but not acted on: terminal_sync (synchronized output is always on), log_level (no log file), disk_free_priv (free space is always the unprivileged figure), keep_dead_proc_usage, proc_info_smaps, and the PCIe keys nvml_measure_pcie_speeds and rsmi_measure_pcie_speeds. The options menu marks these keys "not used yet".
• freq_mode, cpu_sensor and zfs_arc_cached take effect after a restart; the menu says so.

Behaves differently

• Config and themes live under candy-top (not btop), and saves are atomic.
• A save failure or a reload warning opens a warning box; btop only logs it.
• A failed renice opens the error box; btop ignores it.
• Disk IO is shown in bytes per second; btop shows bytes per update interval.
• The disks section is clipped above the bottom border.
• An unreadable /etc/fstab falls back to only_physical; btop shows no disks.
• With cpu_bottom, the battery badge moves to the bottom border.
• The cpu box draws before the first temperature sample arrives.
• Graphs of a disconnected interface keep rebuilding from history.
• Per-core temperatures map core n to sensor n mod sensors unless cpu_core_map says otherwise; btop reads core ids from cpuinfo.
• Batteries are re-scanned every sample, so a hot-plugged one appears without a restart.
• Mounts whose statvfs failed are retried after a while, not ignored for the process lifetime.
• proc_filter_containers also hides VMs, and the text filter also matches container and VM names.
• Containers box (#1873): libvirt/KVM guests are listed beside the containers (engine kvm, the domain's configured memory as the limit when memory.max is max, the vCPU count in the detail title), unless ctr_show_vms is off; btop skips every machine-qemu* scope. The engine candy-top runs in is detected from more markers than btop's three (KUBERNETES_SERVICE_HOST, container= in /proc/1/environ, /proc/self/cgroup, the overlay root in /proc/self/mountinfo; jail on FreeBSD), systemd's names are shortened, and the label takes the x ctr button's own slot cut to fit before the clock and stays clickable (btop prints the whole name two cells further right, with no click zone, whatever the width). Before the first sample the box shows its labels but not "No containers found". [/] with no containers does not reset the proc selection (btop resets it on every press). Conversely, the proc selection also resets when the container selection is cleared because the container vanished or the box was hidden (btop resets it only on a key or click). Container samples come from the proc box's scans, and one covering less than half of update_ms is skipped (btop collects containers on every proc collect). After the box is re-shown, its first cpu% is the sum of the container's processes; btop shows the cgroup delta averaged over the hidden period. The docker reply is capped at 8 MiB and the 1 s timeout bounds the whole exchange. A cgroup path containing .. is never read. Only a bare left click (not a drag) acts on the box's buttons and rows. A translated [ select ] label keeps the button's right edge and splits it into halves. A machine-qemu… scope that does not read as qemu-<id>-<name> once decoded (for example machine-qemubox.scope) is listed as an nspawn container; btop skips every machine-qemu* scope.
• ipmi box (ipmi, I, ipmi_update_ms, ipmi_show_serials): candy-top's own, btop reads no BMC. A stock btop rejects ipmi in shown_boxes or a preset. Like x, I does not act behind the size notice. The IPMI title button is drawn only on hosts with a BMC device node (or while the box is shown).
• VM dashboard (vms, v, s/S, vms_sorting): candy-top's own, btop has no VM view. It is a takeover box: while shown, mem, net, proc and ctr stay in shown_boxes but are not laid out or sampled, and the cpu box is only as tall as its cores need. v also works behind the size notice. A stock btop rejects vms in shown_boxes or a preset, like ctr. The vms title button is drawn only on hosts running libvirt (or while the dashboard is shown). Disk rates are the qemu process's storage I/O, not cgroup io.stat (see vms). FreeBSD bhyve guests are not shown.
• Tree siblings are sorted by branch totals (#1791a).
• Remembered tree collapse choices (#1791c) are stored in $XDG_STATE_HOME/candy-top/tree-state.json, not in btop's internal proc_tree_state config key.
• A remembered tree choice is applied once (at startup, when proc_tree_persist_state is turned on, and on entering the tree view), then only to newly appearing processes. btop re-applies it on every collect. So E is not undone by the next sample, but a process sharing the name chain of one you just collapsed or expanded is not updated until it is recreated or candy-top restarts.
• The IO columns take exactly the 14 cells they draw, so Cpu% stays in place.
• The gpu and gpu memory sorts come after io total in the sort cycle. btop #1552 inserts them before cpu direct; appending them keeps the stock sort positions.
• GPU box drawing is clipped above the box's bottom border; btop overdraws the border when the grid makes a box shorter than its sections.
• A gpuN in shown_boxes that names an accelerator which is not detected is not drawn, and a preset naming one is refused with the size-error box.
• A GPU that stops answering is held only for max(5, ceil(30 s / update_ms)) samples, then shown as n/a; btop holds its last values indefinitely.
• GPUs are sampled once per update for all boxes, as in btop, but nvidia-smi runs in the background, while btop's NVML calls block its collector. So while a query is running, the cpu box's GPU rows arrive a moment after its CPU readings, and the proc box shows the previous sample's per-process GPU values. Per-process data appears one update after the proc box starts wanting it, except after g or a gpu sort, which wait for it.
• With a low update_ms and a slow pmon, the boxes that wait for a GPU sample (the gpu boxes and the cpu box's GPU rows) all get the same snapshot in one burst when the query lands. On a host with more than one GPU vendor, the AMD and Intel sysfs readings are taken in the same sample, so they arrive in that burst too. A vendor removed from shown_gpus is still sampled for one more update, because the other boxes' requests from the previous update still name it. A vendor added is sampled from the next sample.
• F follow and u pause are panel state, not config.
• The banner has no version line.
• The help page indicator sits on the box border.
• Option tab hit-boxes keep btop's fixed widths while the labels are translated.
• The theme list is scanned at startup and on ctrl+r, not on every menu open.
• lowcolor follows truecolor at startup.
• The proc list samples synchronously on the UI loop. Measured on a host with about 1160 processes, a sample takes roughly 40-47 ms with the IO columns off and 56-72 ms with them on.

Development

cd candy-top
composer install
vendor/bin/phpunit

• Golden fixtures. Goldens live under tests/fixtures/ (frames, panels, overlays). Regenerate them with CANDY_TOP_UPDATE_GOLDENS=1 vendor/bin/phpunit <test> and review the diff.
• README tables. The key, config and theme blocks above are generated. After a deliberate roster change, run CANDY_TOP_UPDATE_DOCS=1 vendor/bin/phpunit tests/Docs and review the README diff.
• i18n. User-facing strings are Lang::t() keys in lang/en.php.
• Architecture. For the architecture (Model–Update–View runtime, panel seam, input precedence, overlays) and implementation notes, read CALIBER_LEARNINGS.md at the monorepo root.

License

MIT. The bundled themes and the ported btop logic are Apache-2.0 (Copyright 2021 Aristocratos); see themes/LICENSE.

Credits & inspiration

Design antecedent: aristocratos/btop; SugarCraft is developed as a native PHP project.
