nowo-tech/workflow-bundle

Symfony bundle to define and run Symfony Workflow state machines from database definitions with built-in CRUD.

v1.5.2 2026-07-29 17:49 UTC

Requires

• php: >=8.2 <8.6
• doctrine/doctrine-bundle: ^2.13 || ^3.2.4
• doctrine/orm: ^2.13 || ^3.0
• symfony/config: ^7.0 || ^8.0
• symfony/dependency-injection: ^7.0 || ^8.0
• symfony/form: ^7.0 || ^8.0
• symfony/http-kernel: ^7.0 || ^8.0
• symfony/routing: ^7.0 || ^8.0
• symfony/security-csrf: ^7.0 || ^8.0
• symfony/translation: ^7.0 || ^8.0
• symfony/twig-bundle: ^7.0 || ^8.0
• symfony/validator: ^7.0 || ^8.0
• symfony/workflow: ^7.0 || ^8.0

Requires (Dev)

• friendsofphp/php-cs-fixer: ^3.0
• nowo-tech/phpstan-frankenphp: ^1.0
• phpstan/extension-installer: ^1.4
• phpstan/phpstan: ^2.0
• phpstan/phpstan-phpunit: ^2.0
• phpstan/phpstan-symfony: ^2.0
• phpunit/phpunit: ^10.0 || ^11.0
• rector/rector: ^2.0
• symfony/browser-kit: ^7.0 || ^8.0
• symfony/framework-bundle: ^7.0 || ^8.0
• symfony/security-core: ^7.0 || ^8.0
• symfony/yaml: ^7.0 || ^8.0

Suggests

• symfony/flex: For automatic recipe installation
• symfony/security-bundle: Required for the private Workflow CRUD UI (or set security.allow_unauthenticated for local demos only)

MIT

• Héctor Franco Aceituno
• Nowo.tech

• database
• symfony
• php
• bundle
• workflow
• doctrine
• crud
• state-machine
• symfony-bundle
• frankenphp

Published on Packagist.org on 2026-07-29 17:50 UTC

README

⭐ Found this useful? Give it a star on GitHub! It helps us maintain and improve the project.

Define Symfony Workflow state machines and workflows in the database, manage them with a built-in CRUD UI, and execute transitions at runtime through DatabaseWorkflowRegistry and WorkflowApplicator.

📋 Compatible with Symfony 7.x (PHP 8.2+) and 8.x (PHP 8.4+) — tested on Symfony 7.4, 8.0, and 8.1+.

This bundle is FrankenPHP worker mode friendly.

Features

• Persist workflow definitions (places, transitions, subject class, marking property) in Doctrine
• Configurable Doctrine table_prefix for table and constraint names
• Built-in admin UI at /workflow (configurable path), protected by default via security.access_roles / WorkflowUiAccessCheckerInterface
• Configurable ui.layout_template, ui.css_framework (bootstrap5, tailwind, foundation, custom, …), ui.icon_set, and ui.list_page_size
• UI translations for en, es, fr, it, de, nl, pt (enable extra locales in ui.locales)
• Runtime resolution via DatabaseWorkflowRegistry (Symfony Workflow component)
• WorkflowApplicator helper to apply transitions and flush subjects
• Demo with order approval (state machine) and document review (parallel workflow)
• FrankenPHP worker mode: Supported (tested in the Symfony 8 demo; see Demo with FrankenPHP)

Quick start

composer require nowo-tech/workflow-bundle

# config/packages/nowo_workflow.yaml
nowo_workflow:
    enabled: true
    ui:
        path: '/workflow'
        layout_template: 'base.html.twig'  # project layout
        css_framework: bootstrap5
    security:
        access_roles: [ROLE_ADMIN]

php bin/console nowo:workflow:sync-schema

Demo

make -C demo up-symfony8

Open http://localhost:8022 — try the CRUD at /workflow and playgrounds for orders/documents.

Smoke check (boot + HTTP 200):

make demo-smoke

Documentation

• Installation
• Configuration
• Usage
• Contributing
• Code of Conduct
• Changelog
• Upgrading
• Release
• Security
• Engram
• Spec-driven development
• GitHub Spec Kit

Additional documentation

• Demo with FrankenPHP
• GitHub Actions CI requirements

Tests and coverage

Area	Coverage
PHP	100%

make test
make test-coverage
