Click and Pick for Shopware 6 — Technical Documentation

KommandhubClickAndPickSW adds click-and-collect to Shopware 6.7: a self-pickup shipping method, a pay-on-pickup payment method, pickup-location management with a timezone-aware opening schedule, in-checkout selection of a pickup location + date/ time, server-side validation, a pickup-ready order-delivery state, and Flow Builder triggers/actions for mail and (optional) SMS notifications.

This document targets developers who maintain, test, or extend the plugin. It is not a merchant/end-user guide.

Namespace: Kommandhub\ClickAndPickSW\ → src/ (PSR-4)
Plugin class: Kommandhub\ClickAndPickSW\KommandhubClickAndPickSW
Shopware: ~6.7.0 (shopware/core, shopware/storefront)
License: Proprietary (see LICENSE)

1. Scope

Implemented, and only this:

Pickup-location entity + admin module (address/contact/geo, sales-channel assignment, per-location IANA timezone, weekly opening intervals, special-date overrides).
kommandhub_self_pickup shipping method and kommandhub_pay_on_pickup payment method (payment restricted to the pickup shipping context).
In-checkout pickup-location + pickup date/time + free-text comment selection, persisted in the sales-channel context and validated in the cart.
Order pickup record entity (kommandhub_order_pickup_location) as the single source of truth for an order's pickup data; a OneToOne order extension.
a pickup-ready order-delivery state (technical name ready, added to the order_delivery.state machine); mail templates; pickup.order.placed and pickup.order.ready Flow Builder triggers; admin-mail and optional-SMS actions.
Read-only "Pickup information" tab on the admin order detail page.

Out of scope: capacity/slot-quota booking, cut-off/lead-time rules, blackout periods (there is an extension seam for these — see §12), delivery routing, POS.

2. Architecture & design decisions

Feature-first modules under src/ (mirrors Shopware's own plugin layout). A top-level directory is a boundary; inside it, flat Symfony-idiomatic folders (Service-like classes, Listener, Handler, Struct, Event). One obvious home per class; cross-module access goes through a service, not deep-linking.
DAL-first data model. Pickup data lives in dedicated DAL entities, never in order custom fields. The order's pickup record is a versioned OneToOne extension.
Selection is context state, not cart state. The in-progress selection is stored in the sales_channel_api_context payload via Shopware's SalesChannelContextPersister — the same store as the selected shipping/payment method — so it inherits login-migration, customer scoping, and per-sales-channel isolation for free. The cart validator reads the persisted store (authoritative), never a request-local extension, so a valid selection cannot intermittently disappear between cart recalculations.
Timezone-correct availability. All open/closed decisions are evaluated in the location's own IANA timezone in PHP; opening times are local wall-clock strings.
Autowiring via the ../../* glob (services.yml); autoconfigure: true auto-tags entity definitions, extensions, cart validators, and flow storers. Only Flow actions and the storefront controllers need explicit service config.

3. Project structure

src/
  Checkout/
    Cart/                     PayOnPickupCartProcessor (cart validator) + Error/ blockers
    Payment/                  PayOnPickupPaymentHandler
    PickupSelection/          PickupContextStorage/Keys, StoredPickupSelection (raw),
                              PickupSelection (resolved), OrderPickupLocationWriter
  Entity/
    PickupLocation/           definition/entity/collection + Aggregate/ (OpeningHour,
                              SpecialHour, SalesChannelMapping)
    OrderPickupLocation/      order pickup record entity
    Order/Aggregated/…        OrderDeliveryStates, transition-action constants
  Extension/OrderExtension    OneToOne order → order pickup record
  Event/                      PickupOrderPlacedEvent, PickupOrderReadyEvent
  Flow/
    Aware/                    PickupLocationAware, OrderPickupLocationAware
    Storer/                   flow storers for the two aware contracts
    Action/                   SendPickupNotificationToAdminAction, SendSmsToPickupLocationAction
    Sms/SmsGateway            duck-typed interface for the optional SMS plugin
  Listener/                   SwitchContextEventListener, OrderListener,
                              PickupOrderReadyListener, BusinessEventCollectorListener
  PickupLocation/
    Availability/             PickupLocationAvailabilityService, PickupTimeSlotService
    PickupLocationSelectionResolver, PickupLocationValidator
  Installer/                  PaymentMethodInstaller, ShippingMethodInstaller
  Migration/                  7 migrations (see §14)
  Storefront/Controller/      SalesChannelPickupLocationController
  Twig/FormattedCalendarDays  weekday-name formatting helper
  Resources/
    config/                   services.yml, routes.xml, config.xml
    app/administration/       Vue admin (pickup-location module + order tab)
    app/storefront/           storefront JS plugins (src + built dist)
    views/                    storefront Twig overrides
    snippet/                  storefront snippets (en-GB, de-DE, fr-FR)
    public/                   built administration assets (generated)
tests/
  Unit/                       mirrors src/; no kernel
  Integration/                kernel-backed (@group kernel)

4. Data model & DAL

Table	Entity	Notes
`kommandhub_pickup_location`	`PickupLocationDefinition`	address/contact/geo, `time_format`, `timezone`, `active`, `location_code`. Index on `active`.
`kommandhub_pickup_location_sales_channel`	`…SalesChannelMappingDefinition`	M2M mapping. PK `(pickup_location_id, sales_channel_id)`; FK to `sales_channel` auto-indexes the reverse direction.
`kommandhub_pickup_location_opening_hour`	`…OpeningHourDefinition`	weekly intervals: `day_of_week` (ISO 1–7), `open_time`/`close_time` (`HH:MM`). Index `(pickup_location_id, day_of_week)`.
`kommandhub_pickup_location_special_hour`	`…SpecialHourDefinition`	date overrides: `date`, `closed`, optional `open_time`/`close_time`. Index `(pickup_location_id, date)`.
`kommandhub_order_pickup_location`	`OrderPickupLocationDefinition`	one row per pickup order: `order_id`+`order_version_id`, nullable `pickup_location_id`, `pickup_time`, `comment`.

Associations

PickupLocation.salesChannels — M2M to sales_channel via the mapping table.
PickupLocation.openingHoursSchedule / .specialHours — OneToMany, CascadeDelete.
OrderExtension adds order.kommandhubPickupLocation — OneToOne, autoloaded, CascadeDelete. Every order read (finish page, account, admin API, Flow order data) carries the pickup record without a criteria subscriber.
OrderPickupLocation.pickupLocation — ManyToOne, autoloaded.

Referential integrity

Order pickup record → order FK is (order_id, order_version_id) → order(id, version_id) ON DELETE CASCADE (versioned). Unique on (order_id, order_version_id).
Order pickup record → pickup location FK is ON DELETE SET NULL: deleting a location preserves the order's historical pickup data (time/comment) and nulls the reference. The admin tab renders a "location deleted" state for this case.

5. Cart & checkout lifecycle

Selection is a two-stage value model:

StoredPickupSelection — raw strings read from the context payload.
PickupSelection — resolved: a loaded PickupLocationEntity (+ its schedule associations) plus a parsed \DateTimeImmutable time and comment.

Persisting a selection — SwitchContextEventListener

On SwitchContextEvent::CONSISTENT_CHECK: only acts when the request carries pickupLocationId (so payment/address/language switches never disturb it). An empty value clears the selection (remove control); a value is validated (PickupLocationValidator, an EntityExists on active + assigned-to-sales-channel) and saved via PickupContextStorage.
On SalesChannelContextResolvedEvent (gated on the pickup shipping method, so no lookup on other requests): re-attaches the selection as the pickupLocation context extension for the storefront to read.

Persistence layer — PickupContextStorage wraps SalesChannelContextPersister (load/save/clear). It scopes the payload to the customer only when genuinely logged in (not while an admin impersonates), so token OR customer_id migrates the selection across the guest→customer login token change without leaking between customers or sales channels. Keys are centralized in PickupContextKeys.

Validation gate — PayOnPickupCartProcessor (shopware.cart.validator)

If payment is Pay-on-pickup but the shipping method is not self-pickup → UnsupportedDeliveryMethodCartBlockerError.
If shipping is self-pickup: resolve the selection via PickupLocationSelectionResolver (which reads the persisted store, not the transient extension). No valid location → PickupLocationRequiredCartBlockerError. A chosen time that fails PickupTimeSlotService::isBookable() → InvalidPickupTimeCartBlockerError. All blockers set blockOrder() = true. The read is idempotent across recalculations.

Order placement — OrderListener on CheckoutOrderPlacedEvent

For pickup orders: OrderPickupLocationWriter creates the kommandhub_order_pickup_location row; PickupOrderPlacedEvent is dispatched; the context selection is then cleared so a new cart in the same session starts clean.

6. Pickup scheduling & availability

PickupLocationAvailabilityService (pure, stateless, reads only loaded associations):

isOpenAt(location, ?ref) — open at an instant (special-date override wins over weekly; [open, close) half-open; supports overnight wrap).
isOpenOnDate(location, ?ref) — open at any point on the reference local date (the correct check for the selection list).
getOpenIntervalsForDate(location, date) — concrete {start, end} instants for a date; the seam the slot generator builds on.
filterOpen / filterOpenOnDate — filter loaded collections.

PickupTimeSlotService:

getSlots(location, date, ?now) — steps each open interval by slotStepMinutes (default 30), keeping the whole slot inside the interval and excluding past + disallowed slots.
isBookable(location, when) — the checkout gate: isOpenAt && isAllowed.
protected isAllowed() — returns true; extension seam for cutoff/blackout/ capacity rules (decorate the service and override).

Timezone handling: decisions run in location.timezone (defaults to UTC when unset/invalid). The slots controller builds the requested day at midnight in the location's timezone so it maps to the intended calendar day for any offset. The chosen pickup_time is stored as a DATETIME(3) (offset carried through the ISO-8601 value the storefront submits, parsed back by the resolver).

7. Storefront integration

Twig: views/storefront/component/shipping/custom/shipping-method.html.twig extends the core shipping-method component and renders, under the self-pickup method, a location <select name="pickupLocationId">, a date helper input, a <select name="pickupTime">, and a <textarea name="pickupComment">. Selection reaches the context via the core shipping-form auto-submit (context switch).
The finish page (page/checkout/finish/finish-address.html.twig) renders the pickup card from order.extensions.kommandhubPickupLocation.
JS plugins (app/storefront/src/): SalesChannelPickupLocation fetches the location option list; SalesChannelPickupTime fetches time-slot options for the chosen date and keeps the date helper from auto-submitting the form.
Controller SalesChannelPickupLocationController (storefront route scope):
- …pickup-locations.index — active + sales-channel-assigned locations open on the current date (renders <option> HTML). Filters by salesChannels.id without hydrating the association (avoids per-row over-fetch); loads the schedule associations, batched.
- …pickup-locations.slots — bookable time-slot <option> HTML for a location + date query.

8. Administration integration

Module kommandhub-pickup-location (under Content): list + create/edit, sales-channel assignment, and a schedule editor (kommandhub-pickup-location-schedule) for timezone + weekly intervals + special dates.
Order detail tab kommandhub-order-pickup-info: the child route sw.order.detail.pickup is injected into the core sw.order.detail route via a lightweight module routeMiddleware, and the tab item is added by overriding the sw-order-detail template's sw_order_detail_content_tabs_extension block. The tab component loads the kommandhub_order_pickup_location record by orderId (pickupLocation association) and renders a read-only, deleted-location-aware view (pickup-view.js derives the display state).

9. Flow Builder

Triggers (business events), registered with the flow collector by BusinessEventCollectorListener:

Event name	Class	Dispatched by	Available data
`pickup.order.placed`	`PickupOrderPlacedEvent`	`OrderListener` on order placement	`order`, `pickupLocation`, `pickupOrderLocation`
`pickup.order.ready`	`PickupOrderReadyEvent`	`PickupOrderReadyListener` on delivery entering the `ready` state	`order`, `pickupLocation`, `pickupOrderLocation`

Both implement OrderAware, MailAware, CustomerAware, PickupLocationAware, OrderPickupLocationAware (placed also carries sales-channel-context/group). getMailStruct() targets the order customer, and returns an empty recipient list when the customer/email is missing.

Flow data is restored by storers (auto-tagged flow.storer): PickupLocationFlowStorer and OrderPickupLocationFlowStorer store only the id and lazily reload the entity, so delayed flows stay small. pickupOrderLocation exposes pickupTime/comment (and the linked location) as first-class flow variables.

Actions (flow.action, declared explicitly in services.yml):

action.kommandhub.pickup.notify_admin — SendPickupNotificationToAdminAction: emails the order's pickup location (recipient = location email). Requires OrderAware + PickupLocationAware; pickupOrderLocation is optional template data. Template id comes from the action config or the plugin's seeded default.
action.kommandhub.pickup.notify_sms — SendSmsToPickupLocationAction: texts the location's phone number; appends the pickup time when present.

10. Email & optional SMS

Email: templates are seeded by migrations (…PickupReadyMailTemplate) and sent through the core MailService from the admin-notify action. Template data: order, customer, pickupLocation, pickupOrderLocation.
SMS: a soft dependency on KommandhubSmsSW. The gateway is injected with @?Kommandhub\SmsSW\Notification\Gateway\NotificationGatewayInterface (optional service) and used by duck typing against the local Flow\Sms\SmsGateway interface — this plugin does not require the SMS plugin in composer.json. When absent, the argument is null and the action no-ops. Do not type-hint container services against SmsGateway.

11. Configuration

src/Resources/config/config.xml — three booleans, consumed only in storefront Twig via config('KommandhubClickAndPickSW.config.<key>'):

Key	Default	Effect
`enablePickupLocationSelection`	`true`	gates the in-checkout selector
`showStreetNameInPickupLocationSelectionField`	`false`	street in the option label
`showContactDetailInPickupLocationInfo`	`true`	contact rows in the info card

The admin-notify action reads the sender email from core system config (SystemConfigService), not from plugin config.

12. Extension & customization points

Slot rules: decorate PickupTimeSlotService and override the protected isAllowed() to add cutoff/blackout/capacity logic (used by both slot generation and the checkout gate).
Twig blocks: the storefront shipping-method override and the info card are fully block-wrapped; the admin sw-order-detail tab uses the core extension block.
Flow contracts: PickupLocationAware / OrderPickupLocationAware let other pickup-related events reuse the same storers and actions.
Reuse services, don't reach across modules: PickupLocationSelectionResolver (context → resolved selection), PickupLocationAvailabilityService, PickupContextStorage, OrderPickupLocationWriter.

13. Installation & compatibility (developers)

shopware/core and shopware/storefront ~6.7.0.
PHP 8.2+ (CI runs 8.2; the dev Docker image is dockware/shopware:6.7.8.0).

Composer

Package: kommandhub/click-and-pick-sw. It is proprietary and not on public Packagist, so first make it resolvable — add Kommandhub's private Composer registry, or the Git repository as a VCS source, to your project's composer.json:

"repositories": [
  { "type": "vcs", "url": "git@github.com:KommandHub/KommandhubClickAndPickSW.git" }
]

Then require and enable it from the Shopware project root:

composer require kommandhub/click-and-pick-sw
bin/console plugin:refresh
bin/console plugin:install --activate KommandhubClickAndPickSW
bin/console cache:clear

Update an installed copy:

composer update kommandhub/click-and-pick-sw
bin/console plugin:refresh
bin/console plugin:update KommandhubClickAndPickSW
bin/console cache:clear

Without registry/VCS access, install from a release archive by unpacking it into custom/plugins/KommandhubClickAndPickSW, then run the same plugin:refresh / plugin:install --activate commands. Rebuild assets afterwards when needed (bin/build-administration.sh && bin/build-storefront.sh).

Lifecycle

Install/activate lifecycle (KommandhubClickAndPickSW):

install / update → run the payment + shipping installers (idempotent).
activate / deactivate → activate/deactivate the payment + shipping methods.
Migrations create all tables/state/mail/flow entries.

14. Migrations, update & uninstall

Ordered by timestamp:

1759696668PickupLocation — location + sales-channel mapping tables (+ active index).
1760109246AddReadyForPickupOrderState — pickup-ready ready order_delivery state + transitions.
1760113852PickupReadyMailTemplate — mail template types/templates.
1760115677AddPickupMailSendFlow — flow that sends the customer pickup-ready mail.
1760200000AddPickupAdminNotificationFlow — flow for the admin pickup-order-placed mail.
1760300000NormalizedPickupSchedule — timezone column + opening-hour/special-hour tables.
1760400000OrderPickupLocation — order pickup record table.

Update: update() re-runs the installers so the payment/shipping methods migrate if their ids/classes move; each installer is idempotent.

Uninstall: payment and shipping methods are deactivated, never deleted (historical orders reference them). Without "keep user data", the five plugin tables are dropped child-first (order_pickup_location → opening/special hours → sales-channel mapping → pickup_location) so foreign keys don't block removal. Orders are never deleted.

15. Performance, caching & indexing

Selection lives in the context payload → no cart-payload bloat; reads are single indexed lookups scoped to (token/customer, sales_channel).
The context-resolved listener is gated on the pickup shipping method, so non-pickup requests do zero pickup work.
Storefront index() filters by salesChannels.id without hydrating the association (one fewer batched query + no SalesChannelEntity hydration per row); to-many schedule associations load batched (IN(...)), so there is no N+1.
Indexing: pickup_location.active; mapping PK + FK auto-index cover both directions (InnoDB appends the PK, so a single-column index is effectively (col, id)); schedule aggregates indexed on (pickup_location_id, day_of_week|date); order pickup record unique on (order_id, order_version_id) + index on pickup_location_id.
Availability is computed in PHP (per-location timezone) rather than SQL, so results are not cacheable across timezones — the working sets are small (a merchant's locations), and queries stay index-served.

16. Error handling, logging & debugging

Cart problems surface as blocking Errors (see §5) with message keys under checkout.kommandhub-click-and-pick.* / error.….
An invalid/foreign/inactive location selection throws a ConstraintViolationException at the context switch (aborts the switch).
Flow actions inject a PSR logger and log-and-swallow provider failures (missing template, mail/SMS send errors) so a flow run is not aborted by a notification.
Debugging tips: the selection is in sales_channel_api_context.payload (pickupLocationId/pickupTime/pickupComment); the resolved selection is what the cart validator sees; the order record is in kommandhub_order_pickup_location and on order.extensions.kommandhubPickupLocation.

17. Local development

The plugin ships its own dev stack (docker-compose.yml, Dockerfile, Makefile). Run from the plugin root:

make up            # start the dev stack
make shell         # bash into the app container
make test          # PHPUnit (phpunit.dist.xml). Filter: make test FILTER=SomeTest
make test-coverage # coverage (text + clover + html)
make analyse       # PHPStan (phpstan.dist.neon), src only
make cs / cs-fix   # php-cs-fixer dry-run / apply
make validate-plugin   # shopware-cli store compliance (needs make build)
make zip               # distributable package into build/ (needs make build)
make help          # full target list

Assets (generated; rebuild after changing admin/storefront source):

bin/build-administration.sh && bin/build-storefront.sh

18. Testing

tests/Unit/ mirrors src/; no kernel, PHPUnit TestCase with mocks.
tests/Integration/ is kernel-backed and tagged #[Group('kernel')] (e.g. CartValidationTest); it needs a booted Shopware + database.
Run all: make test. No-kernel (CI-equivalent): --exclude-group kernel.
100% line coverage is enforced in CI (coverage-check … 100); coverage source is src/ excluding Migration/, Resources/, DependencyInjection/, Entity/, and the plugin bootstrap. beStrictAboutCoverageMetadata is on — every test declares #[CoversClass]/#[UsesClass].

19. Static analysis & coding standards

PHPStan level 9 (phpstan.dist.neon), analysing src/.
php-cs-fixer (.php-cs-fixer.dist.php) and a phpcs.dist.xml ruleset.
CI (.github/workflows/php.yml): composer validate → PHP lint → PHPStan → cs-fixer (dry-run) → PHPUnit (no-kernel) with the 100% coverage gate.
Run locally before committing: make cs-fix && make analyse && make test.

20. Known technical limitations

Slot generation offers times but does not enforce capacity/quota, lead-time/ cutoff, or blackout windows — these are the isAllowed() extension seam (§12).
Availability is timezone-evaluated in PHP and not cross-timezone cacheable (small working sets; queries stay index-served).
The SMS integration is best-effort and duck-typed; there is no compile-time guarantee the optional plugin's gateway matches SmsGateway.
Built admin/storefront assets must be regenerated as a release/packaging step.

21. Contributing

See CONTRIBUTING.md for the branch/commit conventions and the required quality gates. In short: branch off develop, keep the change inside its feature module, add/adjust tests with each behavior change, and ensure make cs-fix && make analyse && make test (100% coverage) passes before opening a PR.

22. License

Proprietary — © Kommandhub Limited. Licensed, not sold, for use with Shopware 6 under a separate commercial agreement. See LICENSE. Security policy: SECURITY.md.

kommandhub / click-and-pick-sw

Maintainers

Package info

Statistics

Security
