README

Package to generate Chart.js charts directly from Laravel/Blade, without interacting with JavaScript.

Simple Usage

If you want to generate a chart above, grouping users records by the month of created_at value, here's the code.

Controller:

use LaravelDaily\LaravelCharts\Classes\LaravelChart;

// ...

$chart_options = [
    'chart_title' => 'Users by months',
    'report_type' => 'group_by_date',
    'model' => 'App\Models\User',
    'group_by_field' => 'created_at',
    'group_by_period' => 'month',
    'chart_type' => 'bar',
];
$chart1 = new LaravelChart($chart_options);

return view('home', compact('chart1'));

View File

@extends('layouts.app')

@section('content')
<div class="container">
    <div class="row justify-content-center">
        <div class="col-md-8">
            <div class="card">
                <div class="card-header">Dashboard</div>

                <div class="card-body">

                    <h1>{{ $chart1->options['chart_title'] }}</h1>
                    {!! $chart1->renderHtml() !!}

                </div>

            </div>
        </div>
    </div>
</div>
@endsection

@section('javascript')
{!! $chart1->renderChartJsLibrary() !!}
{!! $chart1->renderJs() !!}
@endsection

Installation

composer require laraveldaily/laravel-charts

No additional configuration or other parameters yet.

Usage

You need to create LaravelChart object in your Controller, passing array of options.

$chart = new LaravelChart($options);

Then pass it to the View, as a variable:

return view('dashboard', compact('chart'));

Available Reports and Options

Currently package support three types of charts/reports:

group_by_date - amount of records from the same table, grouped by time period - day/week/month/year;
group_by_string - amount of records from the same table, grouped by any string field, like name;
group_by_relationship - amount of records from the same table, grouped by belongsTo relationship's field

NOTE: From Laravel 8, all its models are placed in a folder called Models (App\Models)

Example with all options

$chart_options = [
    'chart_title' => 'Transactions by dates',
    'chart_type' => 'line',
    'report_type' => 'group_by_date',
    'model' => 'App\Models\Transaction',
    'conditions'            => [
        ['name' => 'Food', 'condition' => 'category_id = 1', 'color' => 'black', 'fill' => true],
        ['name' => 'Transport', 'condition' => 'category_id = 2', 'color' => 'blue', 'fill' => true],
    ],

    'group_by_field' => 'transaction_date',
    'group_by_period' => 'day',

    'aggregate_function' => 'sum',
    'aggregate_field' => 'amount',
    'aggregate_transform' => function($value) {
        return round($value / 100, 2);
    },

    'filter_field' => 'transaction_date',
    'filter_days' => 30, // show only transactions for last 30 days
    'filter_period' => 'week', // show only transactions for this week
    'continuous_time' => true, // show continuous timeline including dates without data
];

chart_title (required) - just a text title that will be shown as legend;
chart_type (required) - possible values: "line", "bar", "pie";
report_type (required) - see above, can be group_by_date, group_by_string or group_by_relationship;
model (required) - name of Eloquent model, where to take the data from;
name (optional) - just a text title that will be shown as title, otherwise the legend is used;
conditions (optional, only for line chart type) - array of conditions (name + raw condition + color) for multiple datasets;
group_by_field (required) - name of database field that will be used in group_by clause;
group_by_period (optional, only for group_by_date report type) - possible values are "day", "week", "month", "year";
relationship_name (optional, only for group_by_relationship report type) - the name of model's method that contains belongsTo relationship.
aggregate_function (optional) - you can view not only amount of records, but also their SUM() or AVG(). Possible values: "count" (default), "avg", "sum".
aggregate_field (optional) - see aggregate_function above, the name of the field to use in SUM() or AVG() functions. Irrelevant for COUNT().
aggregate_transform (optional) - callback function for additional transformation of aggregate number
filter_field (optional) - show only data filtered by that datetime field (see below)
filter_days (optional) - see filter_field above - show only last filter_days days of that field. Example, last 30 days by created_at field.
filter_period (optional) - another way to filter by field, show only record from last week / month / year. Possible values are "week", "month", "year".
continuous_time (optional) - show all dates on chart, including dates without data.
show_blank_data (optional) - show date even if the data is blank based on filter_days.
range_date_start (optional) - show data in from a date range by filter_field, this is the start date.
range_date_end (optional) - show data in from a date range by filter_field, this is the end date.
field_distinct (optional) - field name required, it will apply a distinct(fieldname)
style_class (optional) - add class css in canvas
date_format (optional) - add the date format, by default: American format Y-m-d
where_raw (optional) - Condition in multiple consultation situations
chart_height (optional) - add the height in options, default 300px
date_format_filter_days (optional) - add the date format for Filter days
withoutGlobalScopes (optional) - removes global scope restriction from queried model
with_trashed (optional) - includes soft deleted models
only_trashed (optional) - only displays soft deleted models
top_results (optional, integer) - limit number of results shown, see Issue #49
chart_color (optional, value in rgba, like "0,255,255") - defines the color of the chart
labels (optional, array with key and value) - defines key value array mapping old and new values
hidden (optional, boolean) hides the current dataset. Useful when having multiple datasets in one chart
stacked (optional, boolean, only for bar chart) stacks the chart data when dates or strings match instead of showing it next to eachother

Example with relationship

$chart_options = [
    'chart_title' => 'Transactions by user',
    'chart_type' => 'line',
    'report_type' => 'group_by_relationship',
    'model' => 'App\Models\Transaction',

    'relationship_name' => 'user', // represents function user() on Transaction model
    'group_by_field' => 'name', // users.name

    'aggregate_function' => 'sum',
    'aggregate_field' => 'amount',

    'filter_field' => 'transaction_date',
    'filter_days' => 30, // show only transactions for last 30 days
    'filter_period' => 'week', // show only transactions for this week
];

Rendering Charts in Blade

After you passed $chart variable, into Blade, you can render it, by doing three actions:

Action 1. Render HTML.

Wherever in your Blade, call this:

{!! $chart1->renderHtml() !!}

It will generate something like this:

<canvas id="myChart"></canvas>

Action 2. Render JavaScript Library

Package is using Chart.js library, so we need to initialize it somewhere in scripts section:

{!! $chart1->renderChartJsLibrary() !!}

It will generate something like this:

<script src="https://cdnjs.cloudflare.com/ajax/libs/Chart.js/2.5.0/Chart.min.js"></script>

Action 3. Render JavaScript of Specific Chart

After Chart.js is loaded, launch this:

{!! $chart1->renderJs() !!}

Using Multiple Charts

You can show multiple charts on the same page, initialize them separately.

Controller:

public function index()
{
    $chart_options = [
        'chart_title' => 'Users by months',
        'report_type' => 'group_by_date',
        'model' => 'App\Models\User',
        'group_by_field' => 'created_at',
        'group_by_period' => 'month',
        'chart_type' => 'bar',
        'filter_field' => 'created_at',
        'filter_days' => 30, // show only last 30 days
    ];

    $chart1 = new LaravelChart($chart_options);


    $chart_options = [
        'chart_title' => 'Users by names',
        'report_type' => 'group_by_string',
        'model' => 'App\Models\User',
        'group_by_field' => 'name',
        'chart_type' => 'pie',
        'filter_field' => 'created_at',
        'filter_period' => 'month', // show users only registered this month
    ];

    $chart2 = new LaravelChart($chart_options);

    $chart_options = [
        'chart_title' => 'Transactions by dates',
        'report_type' => 'group_by_date',
        'model' => 'App\Models\Transaction',
        'group_by_field' => 'transaction_date',
        'group_by_period' => 'day',
        'aggregate_function' => 'sum',
        'aggregate_field' => 'amount',
        'chart_type' => 'line',
    ];

    $chart3 = new LaravelChart($chart_options);

    return view('home', compact('chart1', 'chart2', 'chart3'));
}

View:

@extends('layouts.app')

@section('content')
<div class="container">
    <div class="row justify-content-center">
        <div class="col-md-8">
            <div class="card">
                <div class="card-header">Dashboard</div>

                <div class="card-body">

                    <h1>{{ $chart1->options['chart_title'] }}</h1>
                    {!! $chart1->renderHtml() !!}

                <hr />

                    <h1>{{ $chart2->options['chart_title'] }}</h1>
                    {!! $chart2->renderHtml() !!}

                    <hr />

                    <h1>{{ $chart3->options['chart_title'] }}</h1>
                    {!! $chart3->renderHtml() !!}

                </div>

            </div>
        </div>
    </div>
</div>
@endsection

@section('javascript')
{!! $chart1->renderChartJsLibrary() !!}

{!! $chart1->renderJs() !!}
{!! $chart2->renderJs() !!}
{!! $chart3->renderJs() !!}
@endsection

Multiple Datasets

This is a new feature from v0.1.27. You can provide multiple arrays of settings to the LaravelChart constructor, and they will be drawn on the same chart.

$settings1 = [
    'chart_title'           => 'Users',
    'chart_type'            => 'line',
    'report_type'           => 'group_by_date',
    'model'                 => 'App\Models\User',
    'group_by_field'        => 'created_at',
    'group_by_period'       => 'day',
    'aggregate_function'    => 'count',
    'filter_field'          => 'created_at',
    'filter_days'           => '30',
    'group_by_field_format' => 'Y-m-d H:i:s',
    'column_class'          => 'col-md-12',
    'entries_number'        => '5',
    'translation_key'       => 'user',
    'continuous_time'       => true,
];
$settings2 = [
    'chart_title'           => 'Projects',
    'chart_type'            => 'line',
    'report_type'           => 'group_by_date',
    'model'                 => 'App\Models\Project',
    // ... other values identical to $settings1
];

$chart1 = new LaravelChart($settings1, $settings2);

License

The MIT License (MIT). Please see License File for more information.
