README

Configurable PHP architecture guards — define your layers and rules, then keep them enforced.

Turn architecture rules into executable checks

Make architecture decisions executable, not just documented.
Catch boundary violations before they quietly become conventions.
Tune, override, or skip individual preset rules in native PHP code.

Installation

composer require --dev boundwize/structarmed

Quick start

# defaults to --preset=psr4
vendor/bin/structarmed init

# verify source paths match composer.json PSR-4 mappings
vendor/bin/structarmed init --preset=psr4

# enforce basic coding standard (tags, StudlyCaps, camelCase)
vendor/bin/structarmed init --preset=psr1

# extends PSR-1: require explicit visibility on all members
vendor/bin/structarmed init --preset=psr12

# thin controllers, model/view/service layer rules
vendor/bin/structarmed init --preset=mvc

# layer isolation, entity/VO/repository/event/service conventions
vendor/bin/structarmed init --preset=ddd

# enable all presets at once
vendor/bin/structarmed init --preset=all

Generates a structarmed.php in your project root. Edit it to match your structure, then run:

vendor/bin/structarmed analyse

If violations are found, the output reports each one:

If everything passes, you get a clean summary:

Configuration

Default

<?php

// structarmed.php
use Boundwize\StructArmed\Architecture;
use Boundwize\StructArmed\Preset\Preset;

return Architecture::define()
    ->withPreset(Preset::PSR4());

Multiple presets

->withPresets(Preset::PSR4(), Preset::PSR1(), Preset::PSR12(), Preset::MVC(), Preset::DDD())

Cache directory

StructArmed stores analysis cache in the system temp directory by default. You can configure a project cache directory:

<?php

use Boundwize\StructArmed\Architecture;
use Boundwize\StructArmed\Preset\Preset;

return Architecture::define()
    ->cacheDirectory('var/cache/structarmed')
    ->withPreset(Preset::PSR4());

Relative cache directories are resolved from the project root. --config also controls the cache directory used by analyse and --clear-cache.

Custom layers and rules

<?php

use Boundwize\StructArmed\Architecture;
use Boundwize\StructArmed\Preset\Preset;
use Boundwize\StructArmed\Preset\Presets\DddPreset;
use Boundwize\StructArmed\Rule\Rules\Layer\MayNotDependOnRule;
use Boundwize\StructArmed\Rule\Rules\Method\MustHaveReturnTypeRule;

return Architecture::define()
    ->layer('Domain', 'src/Domain/')
    ->layer('Application', 'src/Application/')
    ->layer('Infrastructure', 'src/Infrastructure/')
    ->skip([
        'tests/Fixtures/',
        'var/cache/*',
        DddPreset::DOMAIN_NO_DATETIME,
        DddPreset::ENTITY_MUST_BE_FINAL => ['src/Legacy/'],
    ])
    ->withPreset(Preset::DDD())
    ->rule(
        'domain.must_not_depend_on_infrastructure',
        new MayNotDependOnRule(from: 'Domain', to: 'Infrastructure', toPath: 'Infrastructure')
    )
    ->rule(
        'domain.public_methods_must_have_return_types',
        new MustHaveReturnTypeRule(layer: 'Domain')
    );

Inside skip(), string entries skip files or directories unless they match a registered rule key, keyed entries skip paths for one specific rule, and rule key constants skip that rule entirely. You can also use skipPath() / skipPaths() and skipRule() / skipRules() when you prefer the explicit methods.

Custom presets

A custom preset is a class that implements Boundwize\StructArmed\Preset\PresetInterface. Inside apply(), add the layers and rules you want to reuse:

<?php

use Boundwize\StructArmed\Architecture;
use Boundwize\StructArmed\Preset\PresetInterface;
use Boundwize\StructArmed\Rule\Rules\Method\MustHaveReturnTypeRule;

final class MyPreset implements PresetInterface
{
    public const METHODS_MUST_HAVE_RETURN_TYPES = 'source.methods_must_have_return_types';

    public function apply(Architecture $architecture): void
    {
        $architecture
            ->layer('Source', 'src/')
            ->rule(
                self::METHODS_MUST_HAVE_RETURN_TYPES,
                new MustHaveReturnTypeRule(layer: 'Source')
            );
    }
}

<?php

use App\Architecture\MyPreset;
use Boundwize\StructArmed\Architecture;

return Architecture::define()
    ->withPreset(new MyPreset());

Override preset rules

Use rule key constants — never raw strings:

<?php

use Boundwize\StructArmed\Architecture;
use Boundwize\StructArmed\Preset\Preset;
use Boundwize\StructArmed\Preset\Presets\DddPreset;
use Boundwize\StructArmed\Rule\Rules\Class_\MustBeFinalRule;
use Boundwize\StructArmed\Rule\Rules\Class_\NamingConventionRule;

return Architecture::define()
    ->layer('Domain',         'src/Domain/')
    ->layer('Application',    'src/Application/')
    ->layer('Infrastructure', 'src/Infrastructure/')
    ->withPreset(Preset::DDD())

    // Replace a rule with a different configuration
    ->replaceRule(
        DddPreset::ENTITY_MUST_BE_FINAL,
        new MustBeFinalRule(layer: 'Domain', classNamePattern: '/Entity$|Aggregate$/')
    )

    // Add your own custom rule
    ->rule(
        'our.handlers.must_be_in_application',
        new NamingConventionRule(
            classNamePattern: '/Handler$/',
            mustBeInLayer: 'Application'
        )
    );

Preset constructor parameters

->withPreset(Preset::DDD(
    maxComplexity:        3,     // default: 5
    maxMethodLength:      15,    // default: 20
    enforceFinalEntities: false, // default: true
))

->withPreset(Preset::MVC(
    controllerMaxComplexity:   3,  // default: 5
    controllerMaxDependencies: 4,  // default: 5
    viewMaxComplexity:         2,  // default: 3
))

->withPreset(Preset::PSR1(
    sourcePaths: ['src/', 'tests/'], // default: read composer.json PSR-4 paths
))

->withPreset(Preset::PSR12(
    sourcePaths: ['src/', 'tests/'], // default: read composer.json PSR-4 paths
))

->withPreset(Preset::PSR4(
    sourcePaths: ['src/', 'tests/'], // default: read composer.json PSR-4 paths
))

Available presets

Preset	Rules
`Preset::PSR1()`	Basic Coding Standard checks: PHP tags, UTF-8 without BOM, symbols vs side effects, PSR-4 class placement, StudlyCaps class names, upper-case class constants, camelCase methods
`Preset::PSR12()`	Extends PSR-1: all methods, constants, and properties must declare explicit visibility
`Preset::PSR4()`	Verifies configured source paths exist in composer.json `autoload` or `autoload-dev` PSR-4 mappings
`Preset::DDD()`	Layer isolation, entity/VO/repository/event/service conventions
`Preset::MVC()`	Layer isolation, thin controllers, model/view/service rules

PHPUnit extension

Run architecture checks as part of your test suite:

<!-- phpunit.xml -->
<extensions>
    <bootstrap class="Boundwize\StructArmed\PHPUnit\StructArmedExtension"/>
</extensions>

Violations cause the test run to fail before any tests execute.

CLI analyse commands

# Analyse with default config discovery
vendor/bin/structarmed analyse
vendor/bin/structarmed analyze

# Analyse only specific paths
vendor/bin/structarmed analyse src
vendor/bin/structarmed analyze src tests

# Custom config path
vendor/bin/structarmed analyse --config=path/to/structarmed.php
vendor/bin/structarmed analyze --config=path/to/structarmed.php

# JSON output (for CI tools)
vendor/bin/structarmed analyse --report=json
vendor/bin/structarmed analyze --report=json

Layer resolution

Layers are resolved by file path — no attributes needed on classes:

src/Domain/     → 'Domain'
src/Application/ → 'Application'
src/Infrastructure/ → 'Infrastructure'

Rule key constants

Every preset rule has a public constant. Use constants, never raw strings:

// ✅ correct — caught by IDE and static analysis
DddPreset::ENTITY_MUST_BE_FINAL

// ❌ wrong — typo silently does nothing
'ddd.entity.must_be_fnal'
